Parameter Description
0-20 Display Line 1.1 Small
Option:
Function:
[1664] Analog Input 54
Actual value at input 54 either as
reference or protection value.
[1665] Analog Output 42
Actual value at output 42 in mA. Use
[mA]
parameter 6-50 Terminal 42 Output to
select the variable to be represented
by output 42.
[1666] Digital Output
Binary value of all digital outputs.
[bin]
[1667] Pulse Input #29
Actual value of the frequency applied
[Hz]
at terminal 29 as a pulse input.
[1668] Pulse Input #33
Actual value of the frequency applied
[Hz]
at terminal 33 as a pulse input.
[1669] Pulse Output #27
Actual value of pulses applied to
[Hz]
terminal 27 in digital output mode.
[1670] Pulse Output #29
Actual value of pulses applied to
[Hz]
terminal 29 in digital output mode.
[1671] Relay Output
View the setting of all relays.
[bin]
[1672] Counter A
View the present value of Counter A.
[1673] Counter B
View the present value of Counter B.
[1675] Analog In X30/11
Actual value of the signal on input
X30/11 (General Purpose I/O Card.
Option)
[1676] Analog In X30/12
Actual value of the signal on input
X30/12 (General Purpose I/O Card.
Optional)
[1677] Analog Out X30/8
Actual value at output X30/8 (General
[mA]
Purpose I/O Card. Optional) Use
6-60 Terminal X30/8 Output to select
the variable to be shown.
[1678] Analog Out X45/1
[mA]
[1679] Analog Out X45/3
[mA]
[1680] Fieldbus CTW 1
Control word (CTW) received from the
Bus Master.
[1682] Fieldbus REF 1
Main reference value sent with
control word via the serial communi-
cations network e.g. from the BMS,
PLC or other master controller.
[1684] Comm. Option
Extended fieldbus communication
STW
option status word.
[1685] FC Port CTW 1
Control word (CTW) received from the
Bus Master.
[1686] FC Port REF 1
Status word (STW) sent to the Bus
Master.
[1690] Alarm Word
One or more alarms in a hex code
(used for serial communications)
MG20O702
Programming Guide
0-20 Display Line 1.1 Small
Option:
[1691] Alarm Word 2
[1692] Warning Word
[1693] Warning Word 2
[1694] Ext. Status Word
[1695] Ext. Status Word
[1696] Maintenance
[1830] Analog Input
[1831] Analog Input
[1832] Analog Input
[1833] Analog Out X42/7
[1834] Analog Out X42/9
[1835] Analog Out
[1836] Analog Input
[1837] Temp. Input
[1838] Temp. Input
[1839] Temp. Input
[1860] Digital Input 2
[2117] Ext. 1 Reference
[2118] Ext. 1 Feedback
[2119] Ext. 1 Output [%]
Danfoss A/S © Rev. 2014-01-21 All rights reserved.
Function:
One or more alarms in a hex code
(used for serial communications)
One or more warnings in a hex code
(used for serial communications)
One or more warnings in a hex code
(used for serial communications)
One or more status conditions in a
hex code (used for serial communi-
cations)
One or more status conditions in a
2
hex code (used for serial communi-
cations)
The bits reflect the status for the
Word
programmed Preventive Maintenance
Events in parameter group 23-1*
Maintenance.
Shows the value of the signal applied
X42/1
to terminal X42/1 on the Analog I/O
card.
Shows the value of the signal applied
X42/3
to terminal X42/3 on the Analog I/O
card.
Shows the value of the signal applied
X42/5
to terminal X42/5 on the Analog I/O
card.
Shows the value of the signal applied
[V]
to terminal X42/7 on the Analog I/O
card.
Shows the value of the signal applied
[V]
to terminal X42/9 on the Analog I/O
card.
Shows the value of the signal applied
X42/11 [V]
to terminal X42/11 on the Analog I/O
card.
X48/2 [mA]
X48/4
X48/7
X48/10
The value of the reference for
[Unit]
extended Closed Loop Controller 1
The value of the feedback signal for
[Unit]
extended Closed Loop Controller 1
The value of the output from
extended Closed Loop Controller 1
3
3
31
