Danfoss VLT AQUA Drive FC 202 Programming Manual page 93

Parameter Description
8-13 Configurable Status Word STW
Option: Function:
to cut out the main voltage from the
frequency converter.
[40] Out of ref.
range
[60] Comparator 0 See parameter group 13-1* Comparators. If
Comparator 0 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
[61] Comparator 1 See parameter group 13-1* Comparators. If
Comparator 1 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
[62] Comparator 2 See parameter group 13-1* Comparators. If
Comparator 2 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
[63] Comparator 3 See parameter group 13-1* Comparators. If
Comparator 3 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
[64] Comparator 4 See parameter group 13-1* Comparators. If
Comparator 4 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
[65] Comparator 5 See parameter group 13-1* Comparators. If
Comparator 5 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
[70] Logic Rule 0 See parameter group 13-4* Logic Rules. If
Logic Rule 0 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
[71] Logic Rule 1 See parameter group 13-4* Logic Rules. If
Logic Rule 1 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
[72] Logic Rule 2 See parameter group 13-4* Logic Rules. If
Logic Rule 2 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
[73] Logic Rule 3 See parameter group 13-4* Logic Rules. If
Logic Rule 3 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
[74] Logic Rule 4 See parameter group 13-4* Logic Rules. If
Logic Rule 4 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
[75] Logic Rule 5 See parameter group 13-4* Logic Rules. If
Logic Rule 5 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
[80] SL Digital See parameter 13-52 SL Controller Action.
Output A The output goes high whenever the Smart
Logic Action [38] Set digital out A high is
executed. The output goes low whenever
the Smart Logic Action [32] Set digital out A
low is executed.
[81] SL Digital See parameter 13-52 SL Controller Action.
Output B The input goes high whenever the Smart
Logic Action [39] Set digital out B high is
executed. The input goes low whenever the
Smart Logic Action [33] Set digital out B low
is executed.
[82] SL Digital See parameter 13-52 SL Controller Action.
Output C The input goes high whenever the Smart
MG20O702
Programming Guide
8-13 Configurable Status Word STW
Option:
[83] SL Digital
Output D
[84] SL Digital
Output E
[85] SL Digital
Output F
Danfoss A/S © Rev. 2014-01-21 All rights reserved.
Function:
Logic Action [40] Set digital out C high is
executed. The input goes low whenever the
Smart Logic Action [34] Set digital out C low
is executed.
See parameter 13-52 SL Controller Action.
The input goes high whenever the Smart
Logic Action [41] Set digital out D high is
executed. The input goes low whenever the
Smart Logic Action [35] Set digital out D low
is executed.
See parameter 13-52 SL Controller Action.
The input goes high whenever the Smart
Logic Action [42] Set digital out E high is
executed. The input goes low whenever the
Smart Logic Action [36] Set digital out E low
is executed.
See parameter 13-52 SL Controller Action.
The input goes high whenever the Smart
Logic Action [43] Set digital out F high is
executed. The input goes low whenever the
Smart Logic Action [37] Set digital out F low
is executed.
