Parameter Description
14-25 Trip Delay at Torque Limit
Range: Function:
60 s [0 - Enter the torque limit trip delay in seconds. When
*
60 s] the output torque reaches the torque limits
(parameter 4-16 Torque Limit Motor Mode and
parameter 4-17 Torque Limit Generator Mode), a
warning is triggered. When the torque limit
warning has been continuously present for the
period specified in this parameter, the frequency
converter trips. Disable the trip delay by setting
the parameter to 60 s = OFF. Thermal frequency
converter monitoring remains active.
14-26 Trip Delay at Inverter Fault
Range: Function:
Size related [0 - 35 s] When the frequency converter detects
*
an overvoltage in the set time, trip is
effected after the set time.
3.13.4 14-3* Current Limit Control
The frequency converter features an integral current limit
controller which is activated when the motor current, and
thus the torque, is higher than the torque limits set in
parameter 4-16 Torque Limit Motor Mode and
parameter 4-17 Torque Limit Generator Mode.
When the current limit is reached during motor operation
or regenerative operation, the frequency converter tries to
reduce torque below the preset torque limits as quickly as
possible without losing control of the motor.
While the current control is active, the frequency converter
can only be stopped by setting a digital input to [2] Coast
inverse or [3] Coast and reset inv. Any signal on terminals
18 to 33 are not active until the frequency converter is no
longer near the current limit.
By using a digital input set to [2] Coast inverse or [3] Coast
and reset inv., the motor does not use the ramp-down
time, since the frequency converter is coasted.
14-30 Current Lim Ctrl, Proportional Gain
Range: Function:
100 % [5 - 500 %] Enter the proportional gain value for the
*
current limit controller. Selection of a high
value makes the controller react faster. Too
high a setting leads to controller
instability.
14-31 Current Lim Ctrl, Integration Time
Range: Function:
Size related [0.002 - 2 s] Controls the current limit control
*
integration time. Setting it to a
lower value makes it react faster. A
setting too low leads to control
instability.
MG20O702
Programming Guide
14-32 Current Lim Ctrl, Filter Time
Range:
Size related
3.13.5 14-4* Energy Optimising
Parameters for adjusting the energy optimisation level in
both Variable Torque (VT) and Automatic Energy Optimi-
zation (AEO) mode.
Automatic Energy Optimisation is only active if 1-03 Torque
Characteristics, is set for either [2] Auto Energy Optim. CT or
[3] Auto Energy Optim. VT.
14-40 VT Level
Range:
66 %
*
%]
NOTICE
This parameter is not active when parameter 1-10 Motor
Construction is set to [1] PM, non-salient SPM.
14-41 AEO Minimum Magnetisation
Range:
Size
related
*
NOTICE
This parameter is not active when parameter 1-10 Motor
Construction is set to [1] PM, non-salient SPM.
14-42 Minimum AEO Frequency
Range:
10 Hz
*
NOTICE
This parameter is not active when parameter 1-10 Motor
Construction is set to [1] PM, non-salient SPM.
Danfoss A/S © Rev. 2014-01-21 All rights reserved.
Function:
[1 - 100 ms] Sets a time constant for the current
*
limit controller low-pass filter.
Function:
NOTICE
[40 - 90
This parameter cannot be adjusted
while the motor is running.
Enter the level of motor magnetisation at low
speed. Selection of a low value reduces
energy loss in the motor, but also reduces
load capability.
Function:
[40 - 75 Enter the minimum allowable magneti-
%] sation for AEO. Selection of a low value
reduces energy loss in the motor, but
can also reduce resistance to sudden
load changes.
Function:
[5 - 40 Hz] Enter the minimum frequency at which the
Automatic Energy Optimisation (AEO) is to
be active.
