Parameter Description
8-14 Configurable Control Word CTW
Option:
[0] None
3
3
[1] Profile default
[2] CTW Valid, active low
3.9.3 8-3* FC Port Settings
8-30 Protocol
Option:
[0] FC
[1] FC MC
[2] Modbus
RTU
[3] Metasys N2
[9] FC Option
8-31 Address
Range:
Size related
*
8-32 Baud Rate
Option:
[0] 2400 Baud
[1] 4800 Baud
[2] 9600 Baud
[3] 19200 Baud
[4] 38400 Baud
[5] 57600 Baud
[6] 76800 Baud
[7] 115200 Baud
The default value depends on the FC Protocol.
8-33 Parity / Stop Bits
Option:
92
Function:
Selection of control word bit 10, if it is
active low or active high.
Function:
Protocol selection for the integrated FC
(standard) Port (RS-485) on the control card.
Communication according to the FC Protocol as
described in RS-485 Installation and Set-up in the
relevant Design Guide.
Same as [0] FC but to be used when
downloading SW to the frequency converter or
uploading dll file (covering information
regarding parameters available in the frequency
converter and their inter-dependencies) to MCT
10 Set-up Software.
Communication according to the Modbus RTU
protocol.
Function:
[ 1 - 255 ] Enter the address for the FC (standard)
port.
Valid range: 1-126.
Function:
Baud rates 9600, 19200, 38400 and 76800
baud are valid for BACnet only.
Function:
Parity and Stop Bits for the protocol
8-30 Protocol using the FC Port. For
Danfoss A/S © Rev. 2014-01-21 All rights reserved.
Programming Guide
8-33 Parity / Stop Bits
Option:
[0] Even Parity, 1 Stop Bit
[1] Odd Parity, 1 Stop Bit
[2] No Parity, 1 Stop Bit
[3] No Parity, 2 Stop Bits
8-35 Minimum Response Delay
Range:
Size related
8-36 Max Response Delay
Range:
Size
related
*
8-37 Maximum Inter-Char Delay
Range:
Size related
3.9.4 8-4* Telegram Selection
8-40 Telegram Selection
Option:
[1]
Standard telegram 1
[100] None
[101] PPO 1
[102] PPO 2
[103] PPO 3
[104] PPO 4
[105] PPO 5
[106] PPO 6
[107] PPO 7
[108] PPO 8
[200] Custom telegram 1
[202] Custom telegram 3
Function:
some of the protocols, not all options
are visible. Default depends on the
protocol selected.
Function:
[ 5 - 10000
Specify the minimum delay time
*
ms]
between receiving a request and
transmitting a response. This is used
for overcoming modem turnaround
delays.
Function:
[ 11 - 10001
Specify the maximum permissible
ms]
delay time between transmitting a
request and receiving a response.
Exceeding this delay time causes
control word time-out.
Function:
[ 0.00 -
Specify the maximum permissible
*
35.01 ms]
time interval between receipt of 2
bytes. This parameter activates time-
out if transmission is interrupted.
Function:
Enables use of freely configurable
telegrams or standard telegrams for
the FC port.
MG20O702
