Danfoss VLT AQUA Drive FC 202 Programming Manual page 32

Parameter Description
0-20 Display Line 1.1 Small
Option:
[1601] Reference [Unit]
3 3
[1602] Reference [%]
[1603] Status Word
[1605] Main Actual Value
[%]
[1609] Custom Readout
[1610] Power [kW]
[1611] Power [hp]
[1612] Motor Voltage
[1613] Frequency
[1614] Motor current
[1615] Frequency [%]
[1616] Torque [Nm]
[1617] Speed [RPM]
[1618] Motor Thermal
[1622] Torque [%]
[1630] DC Link Voltage
[1632] Brake Energy /s
30
Programming Guide
Function:
Total reference (sum of digital/analog/
preset/bus/freeze ref./catch up and
slow-down) in selected unit.
Total reference (sum of digital/analog/
preset/bus/freeze ref./catch up and
slow-down) in percent.
Present status word
One or more warnings in a hex code
View the user-defined readouts as
defined in parameter 0-30 Custom
Readout Unit, parameter 0-31 Custom
Readout Min Value and
parameter 0-32 Custom Readout Max
Value.
Actual power consumed by the motor
in kW.
Actual power consumed by the motor
in hp.
Voltage supplied to the motor.
Motor frequency, i.e. the output
frequency from the frequency
converter in Hz.
Phase current of the motor measured
as effective value.
Motor frequency, i.e. the output
frequency from the frequency
converter in percent.
Present motor load as a percentage
of the rated motor torque.
Speed in RPM (revolutions per
minute) i.e. the motor shaft speed in
closed loop based on the entered
motor nameplate data, the output
frequency and the load on the
frequency converter.
Thermal load on the motor, calculated
by the ETR function. See also
parameter group 1-9* Motor
Temperature.
Shows the actual torque produced, in
percentage.
Intermediate circuit voltage in the
frequency converter.
Present brake power transferred to an
external brake resistor.
Stated as an instantaneous value.
Danfoss A/S © Rev. 2014-01-21 All rights reserved.
0-20 Display Line 1.1 Small
Option: Function:
[1633] Brake Energy /2 Brake power transferred to an
min external brake resistor. The mean
power is calculated continuously for
the most recent 120 s.
[1634] Heatsink Temp. Present heat sink temperature of the
frequency converter. The cut-out limit
is 95 ±5 °C; cutting back in occurs at
70 ±5 °C.
[1635] Inverter Thermal Percentage load of the inverters
[1636] Inv. Nom. Current Nominal current of the frequency
converter
[1637] Inv. Max. Current Maximum current of the frequency
converter
[1638] SL Controller State of the event executed by the
State control
[1639] Control Card Temperature of the control card.
Temp.
[1650] External Sum of the external reference as a
Reference percentage, i.e. the sum of analog/
pulse/bus.
[1652] Feedback[Unit] Signal value in units from the
programmed digital input(s).
[1653] Digi Pot View the contribution of the digital
Reference potentiometer to the actual reference
Feedback.
[1654] Feedback 1 [Unit] View the value of Feedback 1. See
also parameter group 20-0* Feedback.
[1655] Feedback 2 [Unit] View the value of Feedback 2. See
also parameter group 20-0* Feedback.
[1656] Feedback 3 [Unit] View the value of Feedback 3. See
also parameter group 20-0* Feedback.
[1658] PID Output [%] Returns the Drive Closed Loop PID
controller output value in percent.
[1659] Adjusted Setpoint Displays the actual operating set-
point after it is modified by flow
compensation. See parameter group
22-8* Flow Compensation.
[1660] Digital Input Displays the status of the digital
inputs. Signal low = 0; Signal high =
1.
Regarding order, see 16-60 Digital
Input. Bit 0 is at the extreme right.
[1661] Terminal 53 Setting of input terminal 53. Current
Switch Setting = 0; Voltage = 1.
[1662] Analog Input 53 Actual value at input 53 either as a
reference or protection value.
[1663] Terminal 54 Setting of input terminal 54. Current
Switch Setting = 0; Voltage = 1.
