Danfoss VLT AQUA Drive FC 202 Programming Manual page 131

Parameter Description
16-75 Analog In X30/11
Range: Function:
0 [-20 - 20 ] View the actual value at input X30/11 of MCB
*
101.
16-76 Analog In X30/12
Range: Function:
0 [-20 - 20 ] View the actual value at input X30/12 of MCB
*
101.
16-77 Analog Out X30/8 [mA]
Range: Function:
0 [0 - 30 ] View the actual value at input X30/8 in mA.
*
3.15.5 16-8* Fieldbus & FC Port
Parameters for reporting the BUS references and control
words.
16-80 Fieldbus CTW 1
Range: Function:
0 [0 - View the 2-byte control word (CTW) received
*
65535 ] from the bus master. Interpretation of the
control word depends on the fieldbus option
installed and the control word profile selected in
parameter 8-10 Control Profile.
For more information, refer to the relevant
fieldbus manual.
16-82 Fieldbus REF 1
Range: Function:
0 [-200 - View the 2-byte word sent with the control
*
200 ] word from the bus master to set the
reference value.
For more information, refer to the relevant
fieldbus manual.
16-84 Comm. Option STW
Range: Function:
0 [0 - 65535 ] View the extended fieldbus comm. option
*
status word.
For more information, refer to the relevant
fieldbus manual.
16-85 FC Port CTW 1
Range: Function:
0 [0 - View the 2-byte control word (CTW) received
*
65535 ] from the bus master. Interpretation of the
control word depends on the fieldbus option
installed and the control word profile selected
in parameter 8-10 Control Profile.
MG20O702
Programming Guide
16-86 FC Port REF 1
Range:
0 [-200 -
*
200 ]
3.15.6 16-9* Diagnosis Read-Outs
NOTICE
When using MCT 10 Set-up Software, the readout
parameters can only be read online, i.e. as the actual
status. This means that the status is not stored in the
MCT 10 Set-up Software file.
16-90 Alarm Word
Range:
0 [0 - 4294967295 ] View the alarm word sent via the serial
*
16-91 Alarm Word 2
Range:
0 [0 - 4294967295 ] View the alarm word 2 sent via the
*
16-92 Warning Word
Range:
0 [0 - 4294967295 ] View the warning word sent via the
*
16-93 Warning Word 2
Range:
0 [0 - 4294967295 ] View the warning word 2 sent via the
*
16-94 Ext. Status Word
Range:
0 [0 - 4294967295 ] Returns the extended status word sent
*
16-95 Ext. Status Word 2
Range:
0 [0 - 4294967295 ] Returns the extended warning word 2
*
16-96 Maintenance Word
Range:
0 [0 -
4294967295 ]
*
Danfoss A/S © Rev. 2014-01-21 All rights reserved.
Function:
View the 2-byte status word (STW) sent to the
bus master. Interpretation of the status word
depends on the fieldbus option installed and
the control word profile selected in
parameter 8-10 Control Profile.
Function:
communication port in hex code.
Function:
serial communication port in hex code.
Function:
serial communication port in hex code.
Function:
serial communication port in hex code.
Function:
via the serial communication port in hex
code.
Function:
sent via the serial communication port
in hex code.
Function:
Readout of the preventive maintenance
word. The bits reflect the status for the
programmed preventive maintenance events
3 3
