Danfoss VLT AQUA Drive FC 202 Programming Manual page 104

Parameter Description
13-01 Start Event
Option:
[20] Alarm (trip)
[21] Alarm (trip lock)
3 3
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[33] Digital input DI18 Use the value of DI18 in the logic rule
[34] Digital input DI19 Use the value of DI19 in the logic rule
[35] Digital input DI27 Use the value of DI27 in the logic rule
[36] Digital input DI29 Use the value of DI29 in the logic rule
[37] Digital input DI32 Use the value of DI32 in the logic rule
[38] Digital input DI33 Use the value of DI33 in the logic rule
[39] Start command
[40] Drive stopped
[41] Reset Trip
[42] Auto Reset Trip
[43] OK Key
102
Programming Guide
Function:
See parameter group 5-3* Digital
Outputs for further description.
See parameter group 5-3* Digital
Outputs for further description.
Use the result of comparator 0 in the
logic rule.
Use the result of comparator 1 in the
logic rule.
Use the result of comparator 2 in the
logic rule.
Use the result of comparator 3 in the
logic rule.
Use the result of logic rule 0 in the
logic rule.
Use the result of logic rule 1 in the
logic rule.
Use the result of logic rule 2 in the
logic rule.
Use the result of logic rule 3 in the
logic rule.
(High = TRUE).
(High = TRUE).
(High = TRUE).
(High = TRUE).
(High = TRUE).
(High = TRUE).
This event is TRUE if the frequency
converter is started (either via digital
input, fieldbus or other).
This event is TRUE if the frequency
converter is stopped or coasted (either
via digital input, fieldbus or other).
This event is TRUE if the frequency
converter is tripped (but not trip-
locked) and [Reset] is pressed.
This event is TRUE if the frequency
converter is tripped (but not trip-
locked) and an Automatic Reset is
issued.
This event is TRUE if [OK] is pressed.
Danfoss A/S © Rev. 2014-01-21 All rights reserved.
13-01 Start Event
Option: Function:
[44] Reset Key This event is TRUE if [Reset] is pressed.
[45] Left Key
This event is TRUE if [◄] is pressed.
[46] Right Key
This event is TRUE if [►] is pressed.
[47] Up Key
This event is TRUE if [
[48] Down Key
This event is TRUE if [
[50] Comparator 4 Use the result of comparator 4 in the
logic rule.
[51] Comparator 5 Use the result of comparator 5 in the
logic rule.
[60] Logic rule 4 Use the result of logic rule 4 in the
logic rule.
[61] Logic rule 5 Use the result of logic rule 5 in the
logic rule.
[102] Verifying Flow
13-02 Stop Event
Option: Function:
Select the boolean (TRUE or FALSE)
input to deactivate Smart Logic
Control.
[0] False Enters the fixed value of FALSE in the
logic rule.
[1] True Enters the fixed value TRUE in the logic
rule.
[2] Running See parameter group 5-3* Digital
Outputs for further description.
[3] In range See parameter group 5-3* Digital
Outputs for further description.
[4] On reference See parameter group 5-3* Digital
Outputs for further description.
[5] Torque limit See parameter group 5-3* Digital
Outputs for further description.
[6] Current Limit See parameter group 5-3* Digital
Outputs for further description.
[7] Out of current See parameter group 5-3* Digital
range Outputs for further description.
[8] Below I low See parameter group 5-3* Digital
Outputs for further description.
[9] Above I high See parameter group 5-3* Digital
Outputs for further description.
[10] Out of speed
range
[11] Below speed low See parameter group 5-3* Digital
Outputs for further description.
[12] Above speed See parameter group 5-3* Digital
high Outputs for further description.
▲
] is pressed.
▼
] is pressed.
MG20O702
