Danfoss VLT AQUA Drive FC 202 Programming Manual page 156

Parameter Description
8. Program the associated power values in
8a
8b
8c
3 3
8d
9. Switch back with of [Auto On] or [Off].
NOTICE
Set 1-03 Torque Characteristics before tuning takes place.
22-30 No-Flow Power
Range:
0 kW [0 - 0 kW] Read out of calculated no flow power at
*
22-31 Power Correction Factor
Range:
100 [1 -
% 400 %]
*
22-32 Low Speed [RPM]
Range:
Size [ 0 - par.
related 22-36
*
RPM]
22-33 Low Speed [Hz]
Range:
Size [ 0 - par.
related 22-37 Hz]
*
22-34 Low Speed Power [kW]
Range:
Size [ 0 -
related 5.50
*
kW]
154
Programming Guide
parameter 22-34 Low Speed Power [kW]
parameter 22-35 Low Speed Power [HP]
parameter 22-38 High Speed Power [kW]
parameter 22-39 High Speed Power [HP]
Function:
actual speed. If power drops to the display
value, the frequency converter considers the
condition as a no flow situation.
Function:
Make corrections to the calculated power at
parameter 22-30 No-Flow Power.
If no flow is detected, when it should not be
detected, decrease the setting. However, if no
flow is not detected, when it should be
detected, increase the setting to above 100%.
Function:
To be used if parameter 0-02 Motor Speed
Unit has been set for RPM (parameter not
visible if Hz selected).
Set used speed for the 50% level.
This function is used for storing values
needed to tune no flow detection.
Function:
To be used if parameter 0-02 Motor Speed
Unit has been set for Hz (parameter not
visible if RPM selected).
Set used speed for the 50% level.
The function is used for storing values
needed to tune no flow detection.
Function:
To be used if parameter 0-03 Regional
Settings has been set for International
(parameter not visible if North America
selected).
Set power consumption at 50% speed level.
This function is used for storing values
needed to tune no flow detection.
Danfoss A/S © Rev. 2014-01-21 All rights reserved.
22-35 Low Speed Power [HP]
Range: Function:
Size [ 0 - To be used if parameter 0-03 Regional
related 7.50 hp] Settings has been set for North America
*
(parameter not visible if International
selected).
Set power consumption at 50% speed level.
This function is used for storing values
needed to tune no flow detection.
22-36 High Speed [RPM]
Range: Function:
Size [ 0 - To be used if parameter 0-02 Motor Speed
related par. 4-13 Unit has been set for RPM (parameter not
*
RPM]
visible if Hz selected).
Set used speed for the 85% level.
The function is used for storing values
needed to tune no flow detection.
22-37 High Speed [Hz]
Range: Function:
Size [ 0 - To be used if parameter 0-02 Motor Speed
related par. 4-14 Unit has been set for Hz (parameter not
*
Hz] visible if RPM selected).
Set used speed for the 85% level.
The function is used for storing values
needed to tune no flow detection.
22-38 High Speed Power [kW]
Range: Function:
Size [ 0 - To be used if parameter 0-03 Regional
related 5.50 Settings has been set for International
*
kW] (parameter not visible if North America
selected).
Set power consumption at 85% speed level.
This function is used for storing values
needed to tune no flow detection.
22-39 High Speed Power [HP]
Range: Function:
Size [ 0 - To be used if parameter 0-03 Regional
related 7.50 hp] Settings has been set for North America
*
(parameter not visible if International
selected).
Set power consumption at 85% speed level.
This function is used for storing values
needed to tune no flow detection.
3.19.4 22-4* Sleep Mode
If the load on the system allows for stop of the motor and
the load is monitored, the motor can be stopped by
activating the sleep mode function. This is not a normal
stop command, but ramps the motor down to 0 RPM and
MG20O702
