Danfoss VLT AQUA Drive FC 202 Programming Manual page 36

Parameter Description
0-30 Custom Readout Unit
Option:
[171] lb/in²
[172] in WG
[173] ft WG
3 3
[174] in Hg
[180] HP
0-31 Custom Readout Min Value
Range:
Size [ -999999.99 -
related 100.00
*
CustomRea-
doutUnit]
0-32 Custom Readout Max Value
Range:
100 Custom-
ReadoutUnit
*
0-37 Display Text 1
Range:
0 [0 -
*
25 ]
0-38 Display Text 2
Range:
0 [0 -
*
25 ]
34
Function:
Function:
This parameter allows the choice of
the min. value of the custom defined
readout (occurs at zero speed). It is
only possible to select a value
different to 0 when selecting a linear
unit in parameter 0-30 Custom
Readout Unit. For Quadratic and
Cubic units the minimum value is 0.
Function:
[ par. 0-31 - This parameter sets the max
999999.99 value to be shown when the
CustomRea- speed of the motor has reached
doutUnit] the set value for
parameter 4-13 Motor Speed High
Limit [RPM] or
parameter 4-14 Motor Speed High
Limit [Hz] (depends on setting in
parameter 0-02 Motor Speed
Unit).
Function:
In this parameter it is possible to write an
individual text string for display in the LCP or to be
read via serial communication. If to be displayed
permanently select Display Text 1 in 0-20 Display
Line 1.1 Small, 0-21 Display Line 1.2 Small,
0-22 Display Line 1.3 Small, 0-23 Display Line 2 Large
or 0-24 Display Line 3 Large. Press [
◀
change a character. Press [ ] and [
cursor. When a character is highlighted, it can be
▲ ▼
changed. Press [ ] or [ ] to change a character. A
character can be inserted by placing the cursor
between 2 characters and pressing [
Function:
In this parameter it is possible to write an
individual text string for display in the LCP or to be
read via serial communication. If to be displayed
permanently select Display Text 2 in 0-20 Display
Line 1.1 Small, 0-21 Display Line 1.2 Small,
0-22 Display Line 1.3 Small, 0-23 Display Line 2 Large
Danfoss A/S © Rev. 2014-01-21 All rights reserved.
Programming Guide
0-38 Display Text 2
Range:
0-39 Display Text 3
Range:
0 [0 -
*
25 ]
3.2.5 0-4* LCP Keypad
Enable, disable and password protect individual keys on
the LCP.
0-40 [Hand on] Key on LCP
Option:
[0] Disabled
[1] Enabled
[2] Password Avoid unauthorized start in Hand mode. If
▲ ▼
] or [ ] to
▶
] to move the
0-41 [Off] Key on LCP
Option:
[0] Disabled
▲ ▼
[1] Enabled
] or [ ].
[2] Password Avoid unauthorized stop. If parameter 0-41 [Off]
Function:
or 0-24 Display Line 3 Large. Press [
◀
change a character. Press [ ] and [
cursor. When a character is highlighted by the
cursor, this character can be changed. A character
can be inserted by placing the cursor between 2
▲ ▼
characters and pressing [ ] or [
Function:
In this parameter it is possible to write an
individual text string for display in the LCP or to be
read via serial communication. If to be displayed
permanently select Display Text 3 in 0-20 Display
Line 1.1 Small, 0-21 Display Line 1.2 Small,
0-22 Display Line 1.3 Small, 0-23 Display Line 2 Large
or 0-24 Display Line 3 Large. Press [
◀
change a character. Press [ ] and [
cursor. When a character is highlighted by the
cursor, this character can be changed. A character
can be inserted by placing the cursor between 2
▲ ▼
characters and pressing [ ] or [
Function:
Key disabled avoids accidental usage of the key.
[Hand On] key enabled
parameter 0-40 [Hand on] Key on LCP is included in
the My Personal Menu, then define the password
in parameter 0-65 Personal Menu Password.
Otherwise define the password in
parameter 0-60 Main Menu Password.
Function:
Key disabled avoids accidental usage of the key.
[Off] key is enabled
Key on LCP is included in the My Personal Menu,
then define the password in
parameter 0-65 Personal Menu Password. Otherwise
define the password in parameter 0-60 Main Menu
Password.
▲ ▼
] or [ ] to
▶
] to move the
].
▲ ▼
] or [ ] to
▶
] to move the
].
MG20O702
