Danfoss VLT AQUA Drive FC 202 Programming Manual page 34

Parameter Description
0-20 Display Line 1.1 Small
Option:
[2137] Ext. 2 Reference
[Unit]
[2138] Ext. 2 Feedback
3 3
[Unit]
[2139] Ext. 2 Output [%]
[2157] Ext. 3 Reference
[Unit]
[2158] Ext. 3 Feedback
[Unit]
[2159] Ext. 3 Output [%]
[2230] No-Flow Power
[2316] Maintenance Text
[2580] Cascade Status
[2581] Pump Status
[2791] Cascade
Reference
[2792] % Of Total
Capacity
[2793] Cascade Option
Status
[2794] Cascade System
Status
[2795] Advanced
Cascade Relay
Output [bin]
[2796] Extended Cascade
Relay Output
[bin]
[2920] Derag Power[kW]
[2921] Derag Power[HP]
[3110] Bypass Status
Word
[3111] Bypass Running
Hours
[9920] HS Temp. (PC1)
[9921] HS Temp. (PC2)
[9922] HS Temp. (PC3)
[9923] HS Temp. (PC4)
[9924] HS Temp. (PC5)
[9925] HS Temp. (PC6)
[9926] HS Temp. (PC7)
[9927] HS Temp. (PC8)
32
Programming Guide
Function:
The value of the reference for
extended Closed Loop Controller 2
The value of the feedback signal for
extended Closed Loop Controller 2
The value of the output from
extended Closed Loop Controller 2
The value of the reference for
extended Closed Loop Controller 3
The value of the feedback signal for
extended Closed Loop Controller 3
The value of the output from
extended Closed Loop Controller 3
The calculated No Flow Power for the
actual operating speed
Status for the operation of the
Cascade Controller
Status for the operation of each
individual pump controlled by the
Cascade Controller
Reference output for use with
follower drives.
Readout parameter to show the
system operating point as a %
capacity of total system capacity.
Readout parameter to show the status
of the cascade system.
Danfoss A/S © Rev. 2014-01-21 All rights reserved.
0-20 Display Line 1.1 Small
Option: Function:
[9951] PC Debug 0
[9952] PC Debug 1
[9953] PC Debug 2
[9954] PC Debug 3
[9955] PC Debug 4
[9956] Fan 1 Feedback
[9957] Fan 2 Feedback
[9958] PC Auxiliary Temp
[9959] Power Card
Temp.
0-21 Display Line 1.2 Small
Option: Function:
Select a variable for display in line 1,
middle position.
[1601] Analog input The options are the same as those listed
*
53 for 0-20 Display Line 1.1 Small.
0-22 Display Line 1.3 Small
Option: Function:
Select a variable for display in line 1,
right position.
[1614] Motor The options are the same as those listed
*
Current for 0-20 Display Line 1.1 Small.
0-23 Display Line 2 Large
Option: Function:
Select a variable for display in line 2.
[1613] Frequency The options are the same as those listed for
*
0-20 Display Line 1.1 Small.
0-24 Display Line 3 Large
Option: Function:
[1652] Feedback [Unit] The options are the same as those
*
listed for 0-20 Display Line 1.1 Small.
Select a variable for display in line 2.
0-25 My Personal Menu
Array [20]
Range: Function:
Size [0 - Define up to 20 parameters to appear in
related 9999 ] the Q1 Personal Menu, accessible via the
*
[Quick Menu] key on the LCP. The
parameters are displayed in the Q1
Personal Menu in the order they are
programmed into this array parameter.
Delete parameters by setting the value to
'0000'.
For example, this can be used to provide
quick, simple access to just one or up to 50
parameters which require changing on a
regular basis.
