13-40 Logic Rule Boolean 1
Array [6]
Option: Function:
[31] SL Time-out 1 Use the result of timer 1 in the logic
rule.
[32] SL Time-out 2 Use the result of timer 2 in the logic
rule.
[33] Digital input DI18 Use the value of DI18 in the logic rule
(High = TRUE).
[34] Digital input DI19 Use the value of DI19 in the logic rule
(High = TRUE).
[35] Digital input DI27 Use the value of DI27 in the logic rule
(High = TRUE).
[36] Digital input DI29 Use the value of DI29 in the logic rule
(High = TRUE).
[37] Digital input DI32 Use the value of DI32 in the logic rule
(High = TRUE).
[38] Digital input DI33 Use the value of DI33 in the logic rule
(High = TRUE).
[39] Start command This logic rule is TRUE if the frequency
converter is started by any means
(either via digital input, fieldbus or
other).
[40] Drive stopped This logic rule is TRUE if the frequency
converter is stopped or coasted by any
means (either via digital input, fieldbus
or other).
[41] Reset Trip This logic rule is TRUE if the frequency
converter is tripped (but not trip-
locked) and [Reset] is pressed.
[42] Auto Reset Trip This logic rule is TRUE if the frequency
converter is tripped (but not trip-
locked) and an Automatic Reset is
issued.
[43] OK Key This logic rule is TRUE if [OK] is
pressed.
[44] Reset Key This logic rule is TRUE if [Reset] is
pressed.
[45] Left Key This logic rule is TRUE if [◄] is pressed.
[46] Right Key This logic rule is TRUE if [►] is pressed.
[47] Up Key
This logic rule is TRUE if [
[48] Down Key
This logic rule is TRUE if [
[50] Comparator 4 Use the result of comparator 4 in the
logic rule.
[51] Comparator 5 Use the result of comparator 5 in the
logic rule.
[60] Logic rule 4 Use the result of logic rule 4 in the
logic rule.
MG20O702
Programming Guide
13-40 Logic Rule Boolean 1
Array [6]
Option:
[61] Logic rule 5
[70] SL Time-out 3
[71] SL Time-out 4
[72] SL Time-out 5
[73] SL Time-out 6
[74] SL Time-out 7
[80] No Flow
[81] Dry Pump
[82] End of Curve
[83] Broken Belt
[102] Verifying Flow
13-41 Logic Rule Operator 1
Array [6]
Option:
[0] DISABLED
[1] AND
[2] OR
[3] AND NOT
[4] OR NOT
[5] NOT AND
▲
] is pressed.
[6] NOT OR
▼
] is pressed.
[7] NOT AND
NOT
[8] NOT OR NOT
Danfoss A/S © Rev. 2014-01-21 All rights reserved.
Function:
Use the result of logic rule 5 in the
logic rule.
Use the result of timer 3 in the logic
rule.
Use the result of timer 4 in the logic
rule.
Use the result of timer 5 in the logic
rule.
Use the result of timer 6 in the logic
rule.
Use the result of timer 7 in the logic
rule.
Function:
Select the first logical operator to use on the
Boolean inputs from parameter 13-40 Logic
Rule Boolean 1 and parameter 13-42 Logic Rule
Boolean 2.
Parameter numbers in square brackets stand
for the boolean inputs of parameters in group
13-** Smart Logic Control.
Ignores parameter 13-42 Logic Rule Boolean 2,
parameter 13-43 Logic Rule Operator 2, and
parameter 13-44 Logic Rule Boolean 3.
Evaluates the expression [13-40] AND [13-42].
Evaluates the expression [13-40] OR [13-42].
Evaluates the expression [13-40] AND NOT
[13-42].
Evaluates the expression [13-40] OR NOT
[13-42].
Evaluates the expression NOT [13-40] AND
[13-42].
Evaluates the expression NOT [13-40] OR
[13-42].
Evaluates the expression NOT [13-40] AND
NOT [13-42].
Evaluates the expression NOT [13-40] OR NOT
[13-42].
