Parameter Description
Digital input function Option
No operation
Reset
Coast inverse
Coast and reset inverse
DC-brake inverse
Stop inverse
External interlock
Start
Latched start
Reversing [10]
Start reversing [11]
Jog [14]
Preset reference on [15]
Preset ref bit 0 [16]
Preset ref bit 1 [17]
Preset ref bit 2 [18]
Freeze reference [19]
Freeze output [20]
Speed up [21]
Speed down [22]
Set-up select bit 0 [23]
Set-up select bit 1 [24]
Pulse input [32]
Ramp bit 0 [34]
Mains failure inverse [36]
Ref source bit 0 [42]
Hand/Auto Start [51]
Run Permissive [52]
Hand start [53]
Auto start [54]
DigiPot Increase [55]
DigiPot Decrease [56]
DigiPot Clear [57]
Counter A (up) [60]
Counter A (down) [61]
Reset Counter A [62]
Counter B (up) [63]
Counter B (down) [64]
Reset Counter B [65]
Sleep Mode [66]
Reset Maintenance Word [78]
PTC Card 1 [80]
Latched Pump Derag [85]
Lead Pump Start [120]
Lead Pump Alternation [121]
Pump 1 Interlock [130]
Pump 2 Interlock [131]
Pump 3 Interlock [132]
Table 3.9 Functions for Digital Inputs
All = Terminals 18, 19, 27, 29, 32, X30/2, X30/3, X30/4. X30/
are the terminals on MCB 101.
MG20O702
Programming Guide
Terminal
[0] All *term 32, 33, 29, 19
[1] All
[2] All * term 27
[3] All
[5] All
[6] All
[7] All
[8] All
[9] All
All
All
All
All
All
All
All
All
All
All
All
All
All
term 29, 33
All
All
All
All
All
All
All
All
All
All
29, 33
29, 33
All
29, 33
29, 33
All
All
All
All
All
All
All
All
All
All
Danfoss A/S © Rev. 2014-01-21 All rights reserved.
Functions dedicated to only one digital input are stated in
the associated parameter.
All digital inputs can be programmed to these functions:
[0] No operation No reaction to signals transmitted to
terminal.
[1] Reset Resets frequency converter after a TRIP/
ALARM. Not all alarms can be reset.
[2] Coast inverse Leaves motor in free mode. Logic '0'
⇒coasting stop.
(Default Digital input 27): Coasting stop,
inverted input (NC).
[3] Coast and Reset and coasting stop Inverted input (NC).
reset inverse Leaves motor in free mode and resets the
frequency converter. Logic '0'⇒coasting stop
and reset.
[5] DC-brake Inverted input for DC braking (NC).
inverse Stops motor by energising it with a DC
current for a certain time period. See
parameter 2-01 DC Brake Current to
parameter 2-03 DC Brake Cut In Speed [RPM].
The function is only active when the value
in parameter 2-02 DC Braking Time is
different from 0. Logic '0' ⇒DC braking.
This selection is not possible when
parameter 1-10 Motor Construction is set to
[1] PM, non salient SPM.
[6] Stop inverse Stop Inverted function. Generates a stop
function when the selected terminal goes
from logical level '1' to '0'. The stop is
performed according to the selected ramp
time (parameter 3-42 Ramp 1 Ramp Down
Time and parameter 3-52 Ramp 2 Ramp
Down Time.
NOTICE
When the frequency converter is at
the torque limit and has received a
stop command, it may not stop by
itself. To ensure that the frequency
converter stops, configure a digital
output to [27] Torque limit & stop and
connect this digital output to a digital
input that is configured as coast.
[7] External Same function as Coasting stop, inverse, but
Interlock External Interlock generates the alarm
message 'external fault' in the display when
the terminal which is programmed for Coast
Inverse is logic '0'. The alarm message is also
active via digital outputs and relay outputs,
if programmed for External Interlock. The
alarm can be reset using a digital input or
the [Reset] key if the cause for the External
Interlock has been removed. A delay can be
programmed in parameter 22-00 External
Interlock Delay. After applying a signal to the
