Parameter Description
13-10 Comparator Operand
Array [4]
Option:
[112] Logic rule 2
[113] Logic rule 3
[114] Logic rule 4
[115] Logic rule 5
[120] SL Time-out 0
[121] SL Time-out 1
[122] SL Time-out 2
[123] SL Time-out 3
[124] SL Time-out 4
[125] SL Time-out 5
[126] SL Time-out 6
[127] SL Time-out 7
[130] Digital input DI18
[131] Digital input DI19
[132] Digital input DI27
[133] Digital input DI29
[134] Digital input DI32
[135] Digital input DI33
[150] SL digital output A
[151] SL digital output B
[152] SL digital output C
[153] SL digital output D
[154] SL digital output E
[155] SL digital output F
[160] Relay 1
[161] Relay 2
[180] Local referecnce
active
[181] Remote reference
active
[182] Start command
[183] Drive stopped
[185] Drive in hand mode
[186] Drive in auto mode
[187] Start command given
[190] Digital input x30/2
[191] Digital input x30/3
[192] Digital input x30/4
13-11 Comparator Operator
Array [6]
Option: Function:
[0] < Select [0] < for the result of the evaluation to be
TRUE, when the variable selected in
parameter 13-10 Comparator Operand is smaller
than the fixed value in
parameter 13-12 Comparator Value. The result is
FALSE, if the variable selected in
parameter 13-10 Comparator Operand is greater
than the fixed value in
parameter 13-12 Comparator Value.
MG20O702
Programming Guide
Function:
Danfoss A/S © Rev. 2014-01-21 All rights reserved.
13-11 Comparator Operator
Array [6]
Option: Function:
[1] ≈ (equal) Select [1] ≈ for the result of the evaluation to be
TRUE, when the variable selected in
parameter 13-10 Comparator Operand is approxi-
mately equal to the fixed value in
parameter 13-12 Comparator Value.
[2] > Select [2] > for the inverse logic of option [0] <.
[5] TRUE
longer
than..
[6] FALSE
longer
than..
[7] TRUE
shorter
than..
[8] FALSE
shorter
than..
13-12 Comparator Value
Array [6]
Range:
Size [-100000 - Enter the 'trigger level' for the
related 100000 ] variable that is monitored by this
*
comparator. This is an array
parameter containing comparator
values 0 to 5.
3.12.3 13-2* Timers
Use the result (TRUE or FALSE) from timers directly to
define an event (see parameter 13-51 SL Controller Event), or
as boolean input in a logic rule (see parameter 13-40 Logic
Rule Boolean 1, parameter 13-42 Logic Rule Boolean 2 or
parameter 13-44 Logic Rule Boolean 3). A timer is only
FALSE when started by an action (i.e. [29] Start timer 1)
until the timer value entered in this parameter is elapsed.
Then it becomes TRUE again.
All parameters in this parameter group are array
parameters with index 0 to 2. Select index 0 to program
Timer 0, select index 1 to program Timer 1, and so on.
13-20 SL Controller Timer
Array [3]
Range: Function:
Size [ 0 - Enter the value to define the duration of
related 0 ] the FALSE output from the programmed
*
timer. A timer is only FALSE if it is started
by an action (i.e. [29] Start timer 1) and
until the given timer value has elapsed.
