Ext. Closed Loop - Danfoss VLT AQUA Drive FC 202 Programming Manual

Parameter Lists

4.1.18 21-** Ext. Closed Loop

Par. No. #
21-0* Ext. CL Autotuning
21-00
21-01
4 4
21-02
21-03
21-04
21-09
21-1* Ext. CL 1 Ref./Fb.
21-10
21-11
21-12
21-13
21-14
21-15
21-17
21-18
21-19
21-2* Ext. CL 1 PID
21-20
21-21
21-22
21-23
21-24
21-3* Ext. CL 2 Ref./Fb.
21-30
21-31
21-32
21-33
21-34
21-35
21-37
21-38
21-39
21-4* Ext. CL 2 PID
21-40
21-41
21-42
21-43
21-44
21-5* Ext. CL 3 Ref./Fb.
21-50
21-51
21-52
21-53
21-54
21-55
21-57
21-58
21-59
222
Parameter description
Closed Loop Type
PID Performance
PID Output Change
Minimum Feedback Level
Maximum Feedback Level
PID Auto Tuning
Ext. 1 Ref./Feedback Unit
Ext. 1 Minimum Reference
Ext. 1 Maximum Reference
Ext. 1 Reference Source
Ext. 1 Feedback Source
Ext. 1 Setpoint
Ext. 1 Reference [Unit]
Ext. 1 Feedback [Unit]
Ext. 1 Output [%]
Ext. 1 Normal/Inverse Control
Ext. 1 Proportional Gain
Ext. 1 Integral Time
Ext. 1 Differentation Time
Ext. 1 Dif. Gain Limit
Ext. 2 Ref./Feedback Unit
Ext. 2 Minimum Reference
Ext. 2 Maximum Reference
Ext. 2 Reference Source
Ext. 2 Feedback Source
Ext. 2 Setpoint
Ext. 2 Reference [Unit]
Ext. 2 Feedback [Unit]
Ext. 2 Output [%]
Ext. 2 Normal/Inverse Control
Ext. 2 Proportional Gain
Ext. 2 Integral Time
Ext. 2 Differentation Time
Ext. 2 Dif. Gain Limit
Ext. 3 Ref./Feedback Unit
Ext. 3 Minimum Reference
Ext. 3 Maximum Reference
Ext. 3 Reference Source
Ext. 3 Feedback Source
Ext. 3 Setpoint
Ext. 3 Reference [Unit]
Ext. 3 Feedback [Unit]
Ext. 3 Output [%]
Danfoss A/S © Rev. 2014-01-21 All rights reserved.
Programming Guide
Default value
[0] Auto
[0] Normal
0.10 N/A
-999999.000 N/A
999999.000 N/A
[0] Disabled
[0]
0.000 ExtPID1Unit
100.000 ExtPID1Unit
[0] No function
[0] No function
0.000 ExtPID1Unit
0.000 ExtPID1Unit
0.000 ExtPID1Unit
0 %
[0] Normal
0.50 N/A
20.00 s
0.00 s
5.0 N/A
[0]
0.000 ExtPID2Unit
100.000 ExtPID2Unit
[0] No function
[0] No function
0.000 ExtPID2Unit
0.000 ExtPID2Unit
0.000 ExtPID2Unit
0 %
[0] Normal
0.50 N/A
20.00 s
0.00 s
5.0 N/A
[0]
0.000 ExtPID3Unit
100.000 ExtPID3Unit
[0] No function
[0] No function
0.000 ExtPID3Unit
0.000 ExtPID3Unit
0.000 ExtPID3Unit
0 %
4-set-up Change Conver-
during sion index
operation
2 set-ups TRUE -
2 set-ups TRUE -
2 set-ups TRUE -2
2 set-ups TRUE -3
2 set-ups TRUE -3
All set-ups TRUE -
All set-ups TRUE -
All set-ups TRUE -3
All set-ups TRUE -3
All set-ups TRUE -
All set-ups TRUE -
All set-ups TRUE -3
All set-ups TRUE -3
All set-ups TRUE -3
All set-ups TRUE 0
All set-ups TRUE -
All set-ups TRUE -2
All set-ups TRUE -2
All set-ups TRUE -2
All set-ups TRUE -1
All set-ups TRUE -
All set-ups TRUE -3
All set-ups TRUE -3
All set-ups TRUE -
All set-ups TRUE -
All set-ups TRUE -3
All set-ups TRUE -3
All set-ups TRUE -3
All set-ups TRUE 0
All set-ups TRUE -
All set-ups TRUE -2
All set-ups TRUE -2
All set-ups TRUE -2
All set-ups TRUE -1
All set-ups TRUE -
All set-ups TRUE -3
All set-ups TRUE -3
All set-ups TRUE -
All set-ups TRUE -
All set-ups TRUE -3
All set-ups TRUE -3
All set-ups TRUE -3
All set-ups TRUE 0
Type
Uint8
Uint8
Uint16
Int32
Int32
Uint8
Uint8
Int32
Int32
Uint8
Uint8
Int32
Int32
Int32
Int32
Uint8
Uint16
Uint32
Uint16
Uint16
Uint8
Int32
Int32
Uint8
Uint8
Int32
Int32
Int32
Int32
Uint8
Uint16
Uint32
Uint16
Uint16
Uint8
Int32
Int32
Uint8
Uint8
Int32
Int32
Int32
Int32
MG20O702
