Danfoss VLT AQUA Drive FC 202 Programming Manual page 85

Parameter Description
6-24 Terminal 54 Low Ref./Feedb. Value
Range: Function:
0 [-999999.999 - Enter the analog input scaling value that
*
999999.999 ] corresponds to the low voltage/low
current value set in
parameter 6-20 Terminal 54 Low Voltage
and parameter 6-22 Terminal 54 Low
Current.
6-25 Terminal 54 High Ref./Feedb. Value
Range: Function:
100 [-999999.999 - Enter the analog input scaling value
*
999999.999 ] that corresponds to the high voltage/
high current value set in
parameter 6-21 Terminal 54 High
Voltage and parameter 6-23 Terminal 54
High Current.
6-26 Terminal 54 Filter Time Constant
Range: Function:
NOTICE
0.001 s [0.001 -
*
10 s]
This parameter cannot be adjusted
while the motor is running.
Enter the time constant. This is a first-
order digital low pass filter time constant
for suppressing electrical noise in terminal
54. A high time constant value improves
dampening but also increases the time
delay through the filter.
6-27 Terminal 54 Live Zero
Option: Function:
[0] Disabled
[1] Enabled This parameter makes it possible to disable the
Live Zero monitoring. E.g. to be used if the analog
outputs are used as part of a decentral I/O system
(e.g. when not part of any frequency converter
related control functions, but feeding an external
control system with data)
3.8.4 6-3* Analog Input 3 MCB 101
Parameter group for configuring the scale and limits for
analog input 3 (X30/11) placed on option module MCB
101.
6-30 Terminal X30/11 Low Voltage
Range: Function:
0.07 V [ 0 - par. Sets the analog input scaling value to
*
6-31 V] correspond to the low reference/feedback
value (set in parameter 6-34 Term. X30/11
Low Ref./Feedb. Value).
MG20O702
Programming Guide
6-31 Terminal X30/11 High Voltage
Range:
10 V
*
10 V]
6-34 Term. X30/11 Low Ref./Feedb. Value
Range:
0 [-999999.999 -
*
999999.999 ]
6-35 Term. X30/11 High Ref./Feedb. Value
Range:
100
*
999999.999 ]
6-36 Term. X30/11 Filter Time Constant
Range:
0.001 s
*
6-37 Term. X30/11 Live Zero
Option:
[0] Disabled
[1] Enabled
3.8.5 6-4* Analog Input 4 MCB 101
Parameter group for configuring the scale and limits for
analog input 4 (X30/12) placed on option module MCB
101.
6-40 Terminal X30/12 Low Voltage
Range:
0.07 V
*
Danfoss A/S © Rev. 2014-01-21 All rights reserved.
Function:
[ par. 6-30 - Sets the analog input scaling value to
correspond to the high reference/feedback
value (set in parameter 6-35 Term. X30/11
High Ref./Feedb. Value).
Function:
Sets the analog input scaling value to
correspond to the low voltage value
(set in parameter 6-30 Terminal X30/11
Low Voltage).
Function:
[-999999.999 - Sets the analog input scaling value to
correspond to the high voltage value
(set in parameter 6-31 Terminal X30/11
High Voltage).
Function:
NOTICE
[0.001 - 10 s]
This parameter cannot be adjusted
while the motor is running.
A first-order digital low pass filter time
constant for suppressing electrical noise
on terminal X30/11.
Function:
This parameter makes it possible to disable the
Live Zero monitoring. E.g. to be used if the analog
outputs are used as part of a decentral I/O system
(e.g. when not part of any frequency converter
related control functions, but feeding an external
control system with data)
Function:
[ 0 - par. Sets the analog input scaling value to
6-41 V] correspond to the low reference/feedback
value set in parameter 6-44 Term. X30/12
Low Ref./Feedb. Value.
3 3
83
