Danfoss VLT AQUA Drive FC 202 Programming Manual page 190

Parameter Description
26-60 Terminal X42/11 Output
Option:
[108] Torque +-160%
3 3
[109] Out frq 0-Fmax
[113] Ext. Closed Loop
1
[114] Ext. Closed Loop
2
[115] Ext. Closed Loop
3
[139] Bus ctrl.
[141] Bus ctrl t.o.
26-61 Terminal X42/11 Min. Scale
Range:
0 % [0 -
*
200 %]
See principle graph for parameter 6-51 Terminal 42 Output
Min Scale.
26-62 Terminal X42/11 Max. Scale
Range:
100 [0 -
% 200
*
%]
See principle graph for parameter 6-52 Terminal 42 Output
Max Scale.
26-63 Terminal X42/11 Bus Control
Range:
0 % [0 - 100 %] Holds the level of terminal X42/11 if
*
188
Function:
[RPM] and parameter 4-14 Motor Speed
High Limit [Hz]), (0-20 mA)
0-100%, (0-20 mA)
0-100%, (0-20 mA)
0-100%, (0-20 mA)
0-100%, (0-20 mA)
0-100%, (0-20 mA)
Function:
Scale the minimum output of the selected analog
signal at terminal X42/11, as a percentage of the
maximum signal level. E.g. if a 0 V is desired at
25% of the maximum output value. Then
programme 25%. Scaling values up to 100% can
never be higher than the corresponding setting in
parameter 26-62 Terminal X42/11 Max. Scale.
Function:
Scale the maximum output of the selected analog
signal at terminal X42/9. Set the value to the
maximum value of the voltage signal output.
Scale the output to give a voltage lower than 10
V at full scale; or 10 V at an output below 100%
of the maximum signal value. If 10 V is the
desired output current at a value between
0-100% of the full-scale output, programme the
percentage value in the parameter, i.e. 50% = 10
V. If a voltage between 0 and 10 V is desired at
maximum output, calculate the percentage as
follows:
V
10
x 100%
desired maximum voltage
i.e.
10 V
V : x 100% = 200%
5
5 V
Function:
controlled by bus.
Danfoss A/S © Rev. 2014-01-21 All rights reserved.
Programming Guide
26-64 Terminal X42/11 Timeout Preset
Range:
0 %
*
Function:
[0 - 100 %] Holds the preset level of terminal X42/11.
In case a bus time-out and a time-out
function are selected, the output will preset
to this level.
MG20O702
