Parameter Description
3-16 Reference 2 Source
Option:
[0] No function
3 3
[1] Analog Input 53
[2] Analog Input 54
[7] Pulse input 29
[8] Pulse input 33
[20] Digital pot.meter
[21] Analog input
X30/11
[22] Analog input
X30/12
[23] Analog Input
X42/1
[24] Analog Input
X42/3
[25] Analog Input
X42/5
[29] Analog Input
X48/2
[30] Ext. Closed Loop
1
[31] Ext. Closed Loop
2
[32] Ext. Closed Loop
3
[35] Digital input
select
3-17 Reference 3 Source
Option:
[0] No function
[1] Analog Input 53
[2] Analog Input 54
[7] Pulse input 29
58
Programming Guide
Function:
sum of these reference signals defines
the actual reference.
The frequency converter selects AI53 or
AI54 as the reference source basing on
the input signal defined in option [42]
Ref source bit 0 of one of the digital
inputs. For more information, see
parameter group 5-1* Digital Inputs,
option [42] Ref source bit 0.
Function:
NOTICE
This parameter cannot be adjusted
while the motor is running.
Select the reference input to be used for
the third reference signal.
parameter 3-15 Reference 1 Source,
parameter 3-16 Reference 2 Source and
parameter 3-17 Reference 3 Source define
up to 3 different reference signals. The
sum of these reference signals defines
the actual reference.
Danfoss A/S © Rev. 2014-01-21 All rights reserved.
3-17 Reference 3 Source
Option: Function:
[8] Pulse input 33
[20] Digital pot.meter
[21] Analog input
X30/11
[22] Analog input
X30/12
[23] Analog Input
X42/1
[24] Analog Input
X42/3
[25] Analog Input
X42/5
[29] Analog Input
X48/2
[30] Ext. Closed Loop
1
[31] Ext. Closed Loop
2
[32] Ext. Closed Loop
3
[35] Digital input The frequency converter selects AI53 or
select AI54 as the reference source basing on
the input signal defined in option [42]
Ref source bit 0 of one of the digital
inputs. For more information, see
parameter group 5-1* Digital Inputs,
option [42] Ref source bit 0.
3-19 Jog Speed [RPM]
Range: Function:
Size [ 0 - Enter a value for the jog speed n
related par. 4-13 is a fixed output speed. The frequency
*
RPM] converter runs at this speed when the jog
function is activated. The maximum limit is
defined in parameter 4-13 Motor Speed High
Limit [RPM].
See also parameter 3-80 Jog Ramp Time.
3.5.3 3-4* Ramp 1
Configure the ramp parameter, ramping times, for each of
the 2 ramps (parameter group 3-4* Ramp 1 and parameter
group 3-5* Ramp 2).
, which
