Parameter Description
5-30 Terminal 27 Digital Output
Option:
[33]
Safe stop active
[35]
External Interlock
[40]
Out of ref range
3
3
[41]
Below reference, low
[42]
Above ref, high
[45]
Bus ctrl.
[46]
Bus ctrl, 1 if timeout
[47]
Bus ctrl, 0 if timeout
[55]
Pulse output
[60]
Comparator 0
[61]
Comparator 1
[62]
Comparator 2
[63]
Comparator 3
[64]
Comparator 4
[65]
Comparator 5
[70]
Logic rule 0
[71]
Logic rule 1
[72]
Logic rule 2
[73]
Logic rule 3
[74]
Logic rule 4
[75]
Logic rule 5
[80]
SL digital output A
[81]
SL digital output B
[82]
SL digital output C
[83]
SL digital output D
[84]
SL digital output E
[85]
SL digital output F
[90]
kWh counter pulse
[155] Verifying Flow
[160] No alarm
[161] Running reverse
[164] Local ref active, not OFF
[165] Local ref active
[166] Remote ref active
[167] Start command activ
[168] Hand mode
[169] Auto mode
[180] Clock Fault
[181] Prev. Maintenance
[182] Deragging
[183] Pre/Post Lube
[188] AHF Capacitor Connect
[189] External Fan Control
[190] No-Flow
[191] Dry Pump
[192] End Of Curve
[193] Sleep Mode
[194] Broken Belt
[195] Bypass Valve Control
[198] Drive Bypass
74
Programming Guide
Function:
Creates a pulse on the digital
output every time when the
frequency converter uses 1 kWh.
Danfoss A/S © Rev. 2014-01-21 All rights reserved.
5-30 Terminal 27 Digital Output
Option:
[199] Pipe Filling
[200] Full capacity
[201] Pump 1 running
[202] Pump 2 running
[203] Pump 3 running
[204] Pump 4 running
[205] Pump 5 running
[206] Pump 6 running
[207] Pump 7 running
[208] Pump 8 running
[209] Pump 9 running
5-31 Terminal 29 Digital Output
Option:
Function:
[0]
No operation Same options and functions as parameter
*
group 5-3*.
5-32 Term X30/6 Digi Out (MCB 101)
Option:
Function:
[0]
No operation This parameter is active when option module
*
MCB 101 is mounted in the frequency
converter. Same options and functions as
parameter group 5-3*.
5-33 Term X30/7 Digi Out (MCB 101)
Option:
Function:
[0]
No operation This parameter is active when option module
*
MCB 101 is mounted in the frequency
converter. Same options and functions as
parameter group 5-3* Digital Outputs.
3.7.4 5-4* Relays
Parameters for configuring the timing and the output
functions for the relays.
5-40 Function Relay
Option:
[0]
No operation
[1]
Control Ready
[2]
Drive ready
[3]
Drive rdy/rem ctrl
[4]
Stand-by / no warning
[5]
Running
[6]
Running / no warning
[8]
Run on ref/no warn
[9]
Alarm
[10]
Alarm or warning
Function:
Function:
Select options to define the
function of the relays.
The selection of each mechanical
relay is realised in an array
parameter.
MG20O702
