Parameter Description
5-62 Pulse Output Max Freq #27
Range:
3 3
5000 Hz [0 - 32000
*
Hz]
5-63 Terminal 29 Pulse Output Variable
Option:
[0] No operation
[45] Bus ctrl.
[48] Bus ctrl., timeout
[100] Output freq. 0-100
[101] Reference Min-Max
[102] Feedback +-200%
[103] Motor cur. 0-Imax
[104] Torque 0-Tlim
[105] Torque 0-Tnom
[106] Power 0-Pnom
[107] Speed 0-HighLim
[108] Torque +-160%
[109] Out frq 0-Fmax
[113] Ext. Closed Loop 1
[114] Ext. Closed Loop 2
[115] Ext. Closed Loop 3
[116] Cascade Reference
5-65 Pulse Output Max Freq #29
Range:
5000 Hz [0 - 32000
*
Hz]
78
Programming Guide
Function:
NOTICE
This parameter cannot be
adjusted while the motor is
running.
Set the maximum frequency for
terminal 27, corresponding to the
output variable selected in
5-60 Terminal 27 Pulse Output Variable.
Function:
NOTICE
This parameter cannot be
adjusted while the motor is
running.
Select the variable for viewing on the
terminal 29 display. Same options and
functions as parameter group 5-6*
Pulse Output.
Function:
Set the maximum frequency for terminal
29 corresponding to the output variable
set in parameter 5-63 Terminal 29 Pulse
Output Variable.
Danfoss A/S © Rev. 2014-01-21 All rights reserved.
5-66 Terminal X30/6 Pulse Output Variable
Select the variable for read-out on terminal X30/6.
This parameter is active when option module MCB 101 is
installed in the frequency converter.
Same options and functions as parameter group 5-6* Pulse
Outputs.
Option:
[0] No operation
[45] Bus ctrl.
[48] Bus ctrl., timeout
[100] Output freq. 0-100
[101] Reference Min-Max
[102] Feedback +-200%
[103] Motor cur. 0-Imax
[104] Torque 0-Tlim
[105] Torque 0-Tnom
[106] Power 0-Pnom
[107] Speed 0-HighLim
[108] Torque +-160%
[109] Out frq 0-Fmax
[113] Ext. Closed Loop 1
[114] Ext. Closed Loop 2
[115] Ext. Closed Loop 3
[116] Cascade Reference
5-68 Pulse Output Max Freq #X30/6
Range: Function:
5000 Hz [0 - 32000 Select the maximum frequency on
*
Hz] terminal X30/6 referring to the output
variable in 5-66 Terminal X30/6 Pulse
Output Variable.
This parameter is active when option
module MCB 101 is mounted in the
frequency converter.
5-80 AHF Cap Reconnect Delay
Range: Function:
25 s [1 - 120 Delay time between 2 consecutive AHF
*
s] capacitor connections. Timer starts once the
AHF capacitor disconnects, and connects back
once delay expires and drives power above
20% and below 30% of nominal power (see
detailed description below).
AHF capacitor connect output function for digital and
relay outputs
Functional Description:
1. Connect capacitors at 20% nominal power
Hysteresis ±50% of the 20% nominal power
2.
(=min. 10% and max. 30% nominal power)
3. Off delay timer = 10 s. The nominal power must
be below 10% for 10 s to disconnect the
capacitors. If the nominal power exceeds 10%
during the 10 s delay, the timer (10 s) restarts.
Function:
