Electrical Wiring - Danfoss VLT AQUA Drive FC 202 Programming Manual

Introduction
1 1

1.9 Electrical Wiring

1.9.1 Electrical Wiring - Control Cables
3 Phase
power
input
DC bus
+10Vdc
0-10Vdc
0/4-20 mA
0-10Vdc
0/4-20 mA
Illustration 1.2 Basic Wiring Schematic Drawing
A=Analog, D=Digital
Terminal 37 is used for Safe Torque Off. For Safe Torque Off installation instructions, refer to the Operating Instructions.
* Terminal 37 is not included in FC 202 (except enclosure type A1). Relay 2 and terminal 29 have no function in FC 202.
** Do not connect cable screen.
Very long control cables and analog signals may in rare cases and depending on installation result in 50/60 Hz ground loops
due to noise from mains supply cables.
If this occurs, it may be necessary to break the screen or insert a 100 nF capacitor between screen and chassis.
10
Programming Guide
91 (L1)
92 (L2)
93 (L3)
95
PE
88 (-)
Power Supply
89 (+)
15mA
50 (+10 V OUT)
+
S201
53 (A IN)
ON=0-20mA
S202
OFF=0-10V
54 (A IN)
55 (COM A IN)
12 (+24V OUT)
13 (+24V OUT)
P 5-00
18 (D IN)
19 (D IN)
20 (COM D IN)
27
(D IN/OUT)
24V
0V
29
(D IN/OUT)
24V
0V
32 (D IN)
33 (D IN)
*
37 (D IN)
Danfoss A/S © Rev. 2014-01-21 All rights reserved.
Switch Mode
24Vdc
200mA
- + -
24V (NPN)
0V (PNP)
24V (NPN)
(COM A OUT) 39
0V (PNP)
24V (NPN)
S801
0V (PNP)
ON=Terminated
OFF=Open
5V
24V (NPN)
0V (PNP)
S801
RS-485
(P RS-485) 68
Interface
24V (NPN)
(N RS-485) 69
0V (PNP)
24V (NPN)
(COM RS-485) 61
0V (PNP)
(U) 96
(V) 97
(W) 98
(PE) 99
Motor
(R+) 82
Brake
resistor
(R-) 81
relay1
03
240Vac, 2A
02
01
relay2
06
240Vac, 2A
05
400Vac, 2A
04
Analog Output
0/4-20 mA
(A OUT) 42
0V
RS-485
(PNP) = Source
(NPN) = Sink
MG20O702
