1.1 Purpose of the Manual

The Programming Guide provides information required for
programming the frequency converter in a diversity of
applications.
®
VLT is a registered trademark.

1.2 Additional Resources

Other resources are available to understand advanced
frequency converter operation, programming, and
directives compliance.
•
The Operating Instructions provide detailed
information for the installation and start up of
the frequency converter.
•
The Design Guide provides information required
for integration of the frequency converter in a
diversity of applications.
•
The VLT
describe how to use Danfoss frequency
converters in functional safety applications.
•
Supplemental publications and manuals are
available from Danfoss. See danfoss.com/Product/
Literature/Technical+Documentation.htm for
listings.
•
Optional equipment is available, that may change
some of the information described in these
publications. Be sure to see the instructions
supplied with the options for specific
requirements.
Contact a Danfoss supplier or go to www.danfoss.com for
additional information.

1.3 Software Version

This Programming Guide can be used for all FC 200 frequency
converters with software version 2.1x.
The software version number can be seen from
parameter 15-43 Software Version.
4
Programming Guide
®
Safe Torque Off Operating Instructions
Programming Guide
Software version: 2.1x
Danfoss A/S © Rev. 2014-01-21 All rights reserved.

1.4 Approvals

1.5 Symbols

The following symbols are used in this document:
WARNING
Indicates a potentially hazardous situation which could
result in death or serious injury.
CAUTION
Indicates a potentially hazardous situation which could
result in minor or moderate injury. It may also be used
to alert against unsafe practices.
NOTICE
Indicates important information, including situations that
may result in damage to equipment or property.

1.6 Definitions

1.6.1 Frequency Converter

I
VLT,MAX
Maximum output current.
I
VLT,N
Rated output current supplied by the frequency converter.
U
VLT,MAX
Maximum output voltage.

1.6.2 Input

Control command
Start and stop the connected motor by means of LCP and
digital inputs.
Functions are divided into 2 groups.
Functions in group 1 have higher priority than functions in
group 2.
MG20O702
