8.6.5.3

Modem Page

Use the Modem pages to configure or view the primary Transmit parameters and primary Receive
parameters of the SLM-5650B Satellite Modem.
Select the Config, Monitor, Events, Stats, or Utility hyperlink to continue.
8.6.5.3.1

Modem | Config (Modem Configuration)

Modem Operating Mode
Modem Type
OM-73
MIL-165A
IESS-308
IESS-309
IESS-310
TURBO
16-QAM
AUPC
TX-BURST
RX-BURST
RX-BURST-FA
TURBO-FA
Network Processor (NP) Interface
Figure 8-19. Modem | Config (Modem Configuration) Page
Modem Type (read-only)
Linkabit OM-73 modem compatibility mode.
Functionality defined by MIL-STD-188-165A.
Functionality defined by IESS-308, the Intelsat Intermediate Data Rate standard.
Functionality defined by IESS-309, the Intelsat Business Services standard.
Functionality defined by IESS-310, the Intelsat 8-PSK Intermediate Data Rate standard.
Functionality defined by IESS-315 plus Comtech EF Data Turbo mode interoperability.
16-QAM is selected as a modulation type.
Automatic Uplink Power Control is used.
The unit is a Vipersat Remote Modem.
The unit is a Vipersat STDMA Hub Modem with its Acquisition Mode set to "Standard."
The unit is a Vipersat STDMA Hub Modem with its Acquisition Mode set to "Long".
The unit is a Vipersat Hub Expansion Modem.
Description
