1.3.2

Physical Features

1.3.2.1

Front Panel

Chapter 5. FRONT PANEL OPERATION
1
Item
1 USB Port
2 6-button keypad
3 12-button array
4 10 Light-Emitting Diodes (LEDs)
40-character, 2-line Vacuum Fluorescent Display
5
(VFD)
On/Off Power Switch
6
(Illuminated switch optional)
7 Rack handles
Local control of the SLM-5650B is accomplished from the modem's front panel (Figure 1-4). The
function and behavior of the keypad/data entry array, Light Emitting Diode (LED) Indicators, and
Vacuum Fluorescent Display (VFD) are described in detail in Chapter 5.
Introduction
2 3 4

Figure 1-4. SLM-5650B Front Panel

Table 1-1. SLM-5650B Front Panel Features

Description
5
Reserved for future software support
Local control via menu navigation
Manual data entry
Overall status monitoring at a glance
Display of messages, menus and prompts
Unit power
Eases installation into / removal from rack
1–5
SLM-5650B Satellite Modem
Revision 2
7
6
Function
MN-SLM-5650B
