Parameter
Desired Carrier
Input
Power
Maximum Composite
Input Impedance
Input Connectors
Carrier Acquisition Range
Input Return Loss
Buffer Clock
Doppler Buffer
Parameter
Uncoded
Viterbi
Viterbi + Reed-Solomon
Trellis
Trellis + Reed-Solomon
Turbo
LDPC: ULL, LL, and HP
Introduction

Table 1-6. Summary of Demodulator Specifications

Demodulator Specifications
For 70/140 MHz:
For L-Band:
+20 dBm or +40 dBc
50 Ω
TNC for 52 to 88, 104 to 176
Type N for 950 to 2000 MHz
± 30 kHz, selectable
-14 dB (70/140 MHz)
-9 dB (L-Band)
INT, Tx Terrestrial, Rx Satellite
128 to 4,194,304 bits, or 2 to 60 mSec

Table 1-7. Summary of Coding Options

Coding Options
1/1
K=7, 1/2, 3/4, and 7/8 rates
Closed Network, per IESS-308, and IESS-309
IESS-310
IESS-310
Turbo Product Coding (TPC), per IESS-315
Closed Network
1–16
SLM-5650B Satellite Modem
Specifications
+10 to -55 dBm
+10 to -55 dBm (SR>3.2 MSPS)
+10 to 10·log (SR/32000) -75 dBM
10
(SR≤3.2 MSPS) where SR is in symbols per second
Specifications
