Tx Collision Frames
The counters provided in this table are applicable in half-duplex only.
Column
Port
Collision
Late Collision
Single Collision
Multiple Collision
Maximum Collision
Tx Discarded/Filtered
Column
Port
Discarded
Filtered
Network Processor (NP) Interface
The corresponding Ethernet port on the NP Interface and, when in BPM Mode, the base
modem's J5 Ethernet port.
The number of Collision events seen by the GMAC, not including those controls in a
single, Multiple, Excessive or Late.
The number of times a collision is detected later than 512 bits-times into the
transmission of the frame.
The total number of successfully transmitted frames that experienced exactly one
collision.
The total number of successfully transmitted frames that experienced more than one
collision.
The number of frames dropped in the transmit GMAC because the frame experienced
16 consecutive collisions.
The corresponding Ethernet port on the NP Interface and, when in BPM Mode, the base
modem's J5 Ethernet port.
The total number of frames received with either FCS errors or Tx Maximum Collision
frames.
Number of Tx frames filtered. Currently not implemented.
8–47
SLM-5650B Satellite Modem
Description
Description
Revision 2
MN-SLM-5650B
