2.2.1 Optional Rear Support Bracket Kit

Tools needed to install the Bracket Kit:
•
A medium Phillips screwdriver
•
A 5/32-inch SAE Allen Wrench
•
An adjustable Crescent wrench.
To install the kit:
Step Description
Use the #10 flat washers, #10 split washers, and #10 hex nut to secure the #10 shoulder screws to the unit
1
chassis through the rear right and left side slots as shown.
Use the #10 rack bracket bolts to install the rear support brackets onto the rack enclosure threaded rear
2
rails.
Install the unit into the rack enclosure. Ensure that the shoulders of the #10 shoulder screws properly engage
3
into the rear support bracket slots.
Installation 2–4
