Route Table (Display)
This read-only table provides information on a per-route basis:
Column
Index
Route Description
Destination IP/Mask
Interface
Next Hop IP
Add New Route
Take care to accurately create and add new route entries. Existing routes can't be
modified. If a mistake is made when adding a new route entry, the incorrect entry
must be deleted, and then recreated and re-added.
Use this section to add a route entry to the route table. Enter the desired information, and then click
[Add Entry] to add the route. The route will be immediately added to the route table for processing.
Delete Route
Use this section to specify which route table entry to delete when a route is no longer needed, and
then click [Delete Entry] to delete that route table entry.
Network Processor (NP) Interface
Identifies the route entry [1 to 256].
Label that helps users to maintain their network.
Identifies the route to the destination network.
There are two valid selections for routing to a destination network:
toWAN is selected when the route to the destination network is over the satellite link.
The toWAN routes do not need a Next Hop IP Address.
toLAN is used when the route to the destination network is attached to the LAN
interface.
When the route is of type toLAN, the Next Hop IP Address defines the locally attached
router's IP Address. which can be used to route to the destination network. This is the
case when there is another subnet addressed to the modem on the LAN side.
