CENTER 70.000 MHz
*RB 10.0 kHz
CENTER 140.000 MHz
*RB 30.0 kHz
Appendix A
RL -49.00 dBm
ATTEN 10 dB
2.00 dB/DIV
RES BANDWIDTH
10.0 kHz
Modem Rate = 2144 kbit/s, 3/4 Rate Coding
with 7.7 dB Eb/No (S + N)/N = 10 dB
Figure A-2. Typical Output Spectrum – WITH NOISE
RL -20.29 dBm
ATTEN 10 dB
5.00 dB/DIV
CENTER FREQUENCY
140.000 MHz
*VB 3.00 Hz
Figure A-3. Typical Output Spectrum – WITHOUT NOISE
SPAN 1.000 MHz
*VB 10.0 Hz
ST 30.00 sec
PASS
SPAN 5.000 MHz
ST 166.7 sec
A–6
SLM-5650B Satellite Modem
Revision 2
MN-SLM-5650B
