8.6.5.7

Stats (Statistics) Page

Select the Ethernet Tx, Ethernet Rx, IP, WAN, or Clear All hyperlink to continue.
8.6.5.7.1

Stats | Ethernet Tx

Clear/Refresh Ethernet Tx Stats
Click [Clear] to delete all Ethernet Tx statistics (this will also clear all Ethernet Rx statistics).
Click [Refresh] to update the page with the most recent statistics.
Tx Valid Frames
Column
Port
Unicast
Broadcast
Multicast
Pause
Network Processor (NP) Interface
Figure 8-33. Stats | Ethernet Tx Statistics Page
The corresponding Ethernet port on the NP Interface and, when in BPM Mode, the base
modem's J5 Ethernet port.
Number of valid unicast frames transmitted.
Number of valid broadcast frames transmitted.
Number of valid multicast frames transmitted.
Number of PAUSE frames transmitted.
