C.6.9

Network Processor (NP) Interface Commands / Queries

The instruction codes that follow are valid only when the optional Network Processor (NP) Interface Module is installed in the SLM-5650B Satellite
Modem.
Command
Arguments for
Parameter
(Instruction Command or
Code and Response to
Type
Qualifier)
Router Ethernet BRT= 1 byte
Interface Traffic
IP Address and
Range
Router Working GBM= 1 byte
Mode
Router Ethernet
MIP= 18 bytes
Interface
Management IP
Address and
Range
Appendix C
Description of Arguments
Query
Command or Query.
Used to set the NP card's Bridged Point to Multipoint mode,
where:
0 = Off
1 = On
Example: BRT = 0
Command or Query.
Used to set the NP Card's Working Mode where:
1 = Vipersat Hub
2 = Vipersat Hub Expansion
3 = Vipersat Remote
4 = Vipersat Remote Expansion
5 = Multipoint Hub
6 = Multipoint Remote
7 = Point to Point
8 = GigaBit Bridge
Example: GBM = 7
Command or Query.
Used to set the IP address and network prefix for the
NP Interface Management port, in the form aaa.bbb.ccc.ddd.ee,
where:
aaa.bbb.ccc.ddd = IP address
ee = network prefix (0-31)
Example: MIP = 010.006.030.001.24
Response to
Command
BRT=
BRT?
BRT*
BRT#
GBM=
GBM?
GBM*
GBM#
MIP=
MIP?
MIP*
MIP#
C–63
SLM-5650B Satellite Modem
Revision 2
Query
(Instruction
Response to Query
Code and
Qualifier)
BRT? BRT=a
(see Description of
Arguments)
GBM? GBM=a
(see Description of
Arguments)
MIP? MIP=aaa.bbb.ccc.ddd.ee
(see Description of
Arguments)
