Command
Arguments for
Parameter
(Instruction Command or
Code and Response to
Type
Qualifier)
Live Rx Faults N/A 8 bytes
Appendix C
Description of Arguments
Query
Query only.
Live Rx Faults are returned as a 32 bit Hexadecimal value. Bit values
are defined as follows:
80000000 = Demodulator IF not locked
40000000 = Demodulator Data Decoder not locked
20000000 = Demodulator RF Synthesizer not locked
10000000 = Demodulator No IQ Activity
08000000 = Interface De-Multiplexers not locked
04000000 = Interface Buffer Fault
02000000 = Interface Buffer about to slip
01000000 = Interface Buffer has overflowed
00800000 = Interface Buffer has underflowed
00400000 = Interface Buffer Clock PLL not locked
00200000 = Interface Buffer Clock Reference Activity
00100000 = Interface Data/AIS
00080000 = Eb/No Threshold exceeded
00040000 = Composite Power > 40 dBc
00020000 = Composite Power > 20 dBm
00010000 = BERT Sync Loss
00008000 = APC Band Mismatch
00004000 = LNB Voltage out of range
00002000 = LNB Current out of range
Example: RXF = 00000000 indicates No Rx Faults
N/A
C–30
SLM-5650B Satellite Modem
Query
Response to Response to
(Instruction
Command
Code and
Qualifier)
RXF? RXF=xxxxxxxx
(see Description
of Arguments)
