Command
Arguments for
Parameter
(Instruction Command or
Code and Response to
Type
Qualifier)
CnC Power Ratio
N/A 6 bytes
Monitor
Carrier-in-Carrier CRA= 3 bytes
(CnC)
Re-Acquisition
Time
Carrier-in-Carrier
N/A 4 bytes
(CnC) Ratio
Monitor
Carrier-in-Carrier CSD- 6 bytes
(CnC) Min/Max
Search Delay
Appendix C
Description of Arguments
Query
Query only.
When CnC is enabled and locked, the ratio between the interferer
and the desired signal power is readable in dB. The precision is
0.1 dB.
Example 1: CRM = +02.8 (interferer > desired)(format=sdd.d)
Example 2: CRM = LT10.0 (less than -10.0 dB)
Example 3: CRM = GT10.0 (greater than +10.0 dB)
Example 4: CRM = 9999.9 (not locked or CnC not enabled)
Command or Query.
CnC re-Acquisition time in seconds, from 10 to 999. This is the
time wherein CnC will start searching for the delay and frequency
offset if a long duration of unlock occurs.
Example: CRA = 010
Query only.
When CnC is enabled and locked, the ratio between the interferer
and the desired signal power is readable in dB.
Example 1: CRM = +02 (interferer > desired)
Example 2: CRM = LT10 (less than -10 dB)
Example 3: CRM = GT10 (greater than +10 dB)
Example 4: CRM = 99.9 (not locked or CnC not enabled)
Command or Query.
CnC min/max delay value in milliseconds, from 0 to 300 ms in the
form xxxyyy, where:
xxx = min delay
yyy = max delay
Example: CSD = 010300
Response to
Command
N/A
CRA=
CRA?
CRA*
CRA#
N/A
CSD=
CSD?
CSD*
CSD#
C–37
SLM-5650B Satellite Modem
Revision 2
Query
Response to
(Instruction
Query
Code and
Qualifier)
CPR? CPR=xxxxxx
(see Description
of Arguments)
CRA? CRA=xxx
(see Description
of Arguments)
CRM? CRM=xxxx
(see Description
of Arguments)
CSD? CSD=xxxyyy
(see Description
of Arguments)
MN-SLM-5650B
