Rx Error Frames
Column
Port
Invalid FCS
Alignment
Undersized
Oversized
Rx Discarded/Filtered
Column
Port
Discarded
Filtered
Network Processor (NP) Interface
The corresponding Ethernet port on the NP Interface and, when in BPM Mode, the base
modem's J5 Ethernet port.
Total frames received with CRC error.
Total frames received with either Fragments Error or Jabber Error.
Total frames received with a length of less than 64 bytes but with a valid FCS.
Total frame received with a length of more than 1536 bytes but with a valid FCS.
The corresponding Ethernet port on the NP Interface and, when in BPM Mode, the base
modem's J5 Ethernet port.
Total frames received with Undersized, Fragments, Oversized, Jabber, or invalid FCS
errors.
Number of Rx frames filtered. Currently not implemented.
