9.2.7

WAN Menu (W)

When the WAN Menu page is opened from the Main Menu, the following page appears:
The page contains the following options or fields:
Menu Options/Fields
QoS Feature
Global Config & Statistics
Global Con Display
Global Statistics
Class Selector 6
Expedited Forwarding
Assured Forwarding Class 1
Assured Forwarding Class 2
Assured Forwarding Class 3
Assured Forwarding Class 4
Default
Clear (reset) Statistics
NP Interface Telnet/SSH CLI Operation
Entry
Prompts user to select:
Q
0 – Disabled
G
A
B
C
See Chapter Section 8.6.5.5 WAN Page for an overview of
E command functionality and/or information presented for these
functions.
1
2
3
4
D
Provides user with read-only display of the DiffServ default queue.
R
Allows user to reset all DiffServ statistics.
9–28
SLM-5650B Satellite Modem
Description
1 – Enabled
MN-SLM-5650B
Revision 2
