Routing Mode
Item
Gigabit Ethernet Bridge
Router
BPM
Note: In BPM Mode, the Gigabit Ethernet Bridge option becomes inaccessible and the appearance
of the Routing Mode section changes as follows:
Click [Submit] once the appropriate operating mode is selected on this page.
Network Processor (NP) Interface
Select for use in a Point-to-Point SCPC link when you wish to bridge traffic (no IP
network routing).
Note: This mode is currently only compatible with the Gigabit Ethernet bridge card for the
modem. Ethernet communication between the Base Modem and the NP Interface is
disabled, as the Base Modem does not support secure network management interfaces
When the modem is operating in Router Mode, a number of Base Modem M&C
parameters are available via the NP HTTP Interface. Similarly, a limited number of
status-only NP parameters are viewable over the Base Modem HTTP Interface.
When BPM Mode is selected, the NP Interface Ethernet ports P1 through P4
transparently bridge data traffic, and network management is only possible using the
Base Modem's J5 Ethernet port.
8–14
SLM-5650B Satellite Modem
Description
Revision 2
MN-SLM-5650B
