Command
Arguments for
Parameter
(Instruction Command or
Code and Response to
Type
Qualifier)
Rx RCW= 1 byte
Reed-Solomon
Code Word
Rx Differential RDD= 1 byte
Decoding
Rx Data Fault RDF= 1 byte
Rx Data Invert RDI= 1 byte
Appendix C
Description of Arguments
Query
Command or Query.
Rx RS encoding in the form x, where:
0 = RS(225,205,10)
1 = RS(219,201,9)
2 = RS(208,192,8)
3 = RS(194,178,8)
4 = RS(126,112,7)
5 = RS(220,200,10)
Depending on Modem mode, overhead type, and data rate, not all
selections will be valid.
Example: RCW = 0 (This is a 'don't care' if RS is Off under TRS)
Command or Query.
Rx Differential Decoding in the form x, where:
0 = Off
1 = On
Depending on FEC type or Modulation Type, not all selections will be
valid.
Example: RDD = 1 (selects Rx Differential Decoding On)
Command or Query.
Receive Data Fault, where:
0 = None
1 = DATA
2 = AIS
Example: RDF = 0 (selects Data Fault = None)
Command or Query.
Invert Receive Data, where:
0 = Normal
1 = Inverted
Example: RDI = 1 (selects Inverted RX Data)
RCW =
RCW?
RCW *
RCW #
RDD=
RDD?
RDD*
RDD#
RDF =
RDF?
RDF*
RDF#
RDI =
RDI?
RDI*
RDI#
C–26
SLM-5650B Satellite Modem
Query
Response to Response to
(Instruction
Command
Code and
Qualifier)
RCW? RCW=x
(see Description
of Arguments)
RDD? RDD=x
(see Description
of Arguments)
RDF? RDF=x
(see Description
of Arguments)
RDI? RDI=x
(see Description
of Arguments)
