Command
Arguments for
Parameter
(Instruction
Command or
Code and
Response to
Type
Qualifier)
Rx Reed-
RRD=
1 byte
Solomon
Interleaver Depth
Rx Reed-
RRS=
1 byte
Solomon
Decoding
Rx Spreading
RSE=
5 bytes
Equation
Rx Spreading
RSF=
4 bytes
Factor
Rx Spectrum
RSI=
1 byte
Invert
Appendix C
Description of Arguments
Query
Command or Query.
Rx RS encoding, where:
0 = Interleaver Depth 4
1 = Interleaver Depth 8
2 = Interleaver Depth 16
Depending on Modem mode, overhead type, and data rate, not all
selections will be valid.
Example: RRD = 0 (This is a 'don't care' if RS is Off under RRS)
Command or Query.
Rx RS encoding, where:
0 = Off
1 = On
Depending on Modem mode, not all selections will be valid.
Example: RRS = 0 (RS encoding is Off)
Command or Query.
Rx Speading Equation, where:
a = Equation 0 or 1:
bbbb = GSN 0-9999
Example: RSE = 00000 (Rx Equation 0 GSN 0000)
Command or Query.
Rx Spreading Factor, where xxxx is value from 1 to 512. Values other
than 1 are only valid when Modem Type = LDPC.
Example: RSF = 0001 (Rx Spreading Off)
Command or Query.
Rx Spectrum Invert, where:
0 = Normal
1 = Rx Spectrum Invert
Example: RSI = 0 (selects Normal)
RRD =
RRD?
RRD *
RRD #
RRS=
RRS?
RRS*
RRS#
RSE=
RSE?
RSE*
RSE#
RSF=
RSF?
RSF*
RSF#
RSI=
RSI?
RSI*
RSI#
C–28
SLM-5650B Satellite Modem
Query
Response to
Response to
(Instruction
Command
Code and
Qualifier)
RRD?
RRD =x
(see Description
of Arguments)
RRS?
RRS=x
(see Description
of Arguments)
RSE?
RSE= abbbb
(see Description
of Arguments)
RSF?
RSF=xxxx
(see Description
of Arguments)
RSI?
RSI=x
(see Description
of Arguments)
MN-SLM-5650B
Revision 2
Query
