Table 3-1. Slm-5650B Rear Panel Connectors - Comtech EF Data SLM-5650B Installation And Operation Manual

Connector Group
(Chapter Sect.)
IF J2 Tx
(Sect. 3.2)
J11 Tx
J4 Rx
J3 Rx
Terrestrial Data J5 Ethernet
(Sect. 3.3)
P1 Overhead Data
J6 EIA-530
J7 HSSI
J12 Traffic 100/1000
(Interface Option Slot)
Utility J1 Ext Ref
(Sect. 3.4)
J8 Alarms
J9 Auxiliary
J10 Remote
Power/Ground AC
(Sect 3.5)
DC
Ground
To maintain compliance with the European EMC Directive 2004/108/EEC (EN 55022,
EN-55024), properly shielded cables are required for all data I/O.
The 'D-Shell' connectors (J6, J8, J9, J10, P1) provided on the SLM-5650B rear panel
feature threaded nuts to ensure the mechanical integrity of the mated connections.
Rear Panel Connectors and Pinouts

Table 3-1. SLM-5650B Rear Panel Connectors

Ref Des / Name
Type 'N' female (L-Band)
TNC female (70/140MHz band)
Type 'N' female (L-Band)
TNC female (70/140MHz band)
RJ-45 female
25-pin Type 'D' male
25-pin Type 'D' female
50-pin female
See Sect. 3.3.5
TNC female
9-pin Type 'D' female
15-Pin Type 'HD' Female
9-pin Type 'D' female
See Sect. 3.5.1
N/A
#10-32 stud
Connector Type
2
2
2
2
2
3–2
SLM-5650B Satellite Modem
Revision 2
Function
IF Output
IF Input
10/100Base-T, Remote Control
See Sect. 3.3.2 for details
Data I/O to 20 Mbps
Data I/O to 51.84 Mbps
Supports optional data interfaces
Modem Reference I/O
Form C Alarms (relay closures)
See Sect. 3.4.3 for details
Serial Remote Interface (RS232/485)
Chassis power
Chassis power
Common Chassis Ground
MN-SLM-5650B
