CONFIG: Remote  SerialConfig  Baudrate
Local M&C Bus Baud Rate:
Use the  arrow keys to select a Baud Rate of 2400, 4800, 9600, 19200, 38400
(default), 57600, or 115200, and then press [ENT].
CONFIG: Remote  Ethernet Config
Ethernet Config:
Gateway
Use the arrow keys to select IP Address/Range, MAC, Gateway, SNMP, or Option
Card Addr, and then press [ENT].
Option
IP
Address/Range
MAC
Gateway
SNMP
Option Card
Addr
CONFIG: Remote  EthernetConfig  SNMP
SNMP: Version
Use the arrow keys to select Version, Communities, or Traps, and then press
[ENT].
Front Panel Operation
38400 Baud
IP Address/Range
SNMP Option Card Addr
Function
Select the IP Address.
Displays the modem's MAC Address: This is programmed at the factory and is not
user changeable. If installed, the Gigabit Ethernet Interface's MAC Address will also
be displayed.
The IP Gateway Address is the default address that the modem will send all IP
responses when the message originated from a source outside the modems local
attached network.
Select the Version, Communities or Traps. Detailed information follows.
Select the NP Card Address Mode, Security, BPM, Traffic, IP, and Mgmt IP.
Communities
CONFIG: Remote  EthernetConfig  SNMP  Version
SNMP Version: SNMP V1/V2c
Use the arrow keys to select SNMP V1/V2c or SNMP V3, and then press
[ENT].
(E)
MAC
(E)
Traps
(E)
(E)
