1.4

Summary of Specifications

Parameter
Operating Frequency Range
Modulation Types
Digital Data Rates
Symbol Rate Range
EXT REF Input
INT REF Stability
Scrambling
IDR/IBS Framing Compatibility
Built-in Test (BIT)
Summary Faults
Monitor and Control
Introduction

Table 1-4. Summary of General Specifications

General Specifications
52 to 88, 104 to 176, 950 to 2000 MHz ( in 100 Hz steps)
BPSK, QPSK, OQPSK, 8PSK, 8QAM, 16QAM
• 64 kbps to 20 Mbps, in 1 bps steps (EIA-530, EIA-613)
• 64 kbps to 51.840 Mbps, in 1 bps steps (EIA-613, LVDS)
• 64 kbps to 155.52 Mbps, in 1 bps steps (GigE Bridge, Network Processor)
32 Ks/s to 64 Ms/s
TNC Connector, 1, 5, or 10 MHz selectable
5 x 10
-8
V.35, OM-73, and Synchronous
Support for IBS and IDR framing. Allows basic IBS/IDR Open Network capable
operation
Fault and status reporting, BER performance monitoring, IF Loop-back,
programmable test modes, built-in Fireberd emulation with all comprehensive
BER measurements.
Reported via Front Panel LEDs, 9-pin D-sub Alarm connector, relay contacts for
Tx, Rx, Common equipment faults, and Tx and RX alarms. Open collector faults
on the 15-pin D-sub Aux connector. Both data interfaces have open collector
faults available.
EIA-485, EIA-232, 10/100BASE-T Ethernet with HTTP, HTTPS, Telnet, and SNMP
1–14
