9.2.8

Routing Table (R)

When the Routing Table page is opened from the Main Menu, static routes can be entered into the
IP Module to route IP traffic over the satellite or to another device on the local LAN. Route entries
can be in any combination of Unicast and Multicast routes. The Routing Table page contains the
following options or fields:
The page contains the following options or fields:
Menu Options/Fields
Add entry
Modify Entry
Delete Entry
Previous Page
Next Page
NP Interface Telnet/SSH CLI Operation
Entry
A
Refer to Chapter Section 8.6.5.6.1 Routing | Routes for an overview
M
of command functionality.
D
P
Allows user to navigate, on a per-page basis, between the start and
end of the Routing Table.
N
9–29
SLM-5650B Satellite Modem
Description
MN-SLM-5650B
Revision 2
