8.6.5.3.4

Modem | Stats (Modem Statistics Log)

Clear/Refresh Modem Statistics
Click [Clear] to delete all log entries.
Click [Refresh] to refresh the Link Statistics Log to display the most recent entries.
Logging Interval
Use the drop-down menu to set the statistics recording interval. Valid settings are from every 10
minutes to every 90 minutes in 10-minute increments, or Disabled.
Click [Submit] to save all changes made to this page.
Link Statistics Log
Displays the following modem statistics (all information is read only):
Column
Index
Min Eb/No
Avg Eb/No
Date
Time
Network Processor (NP) Interface
Figure 8-22. Modem | Stats (Modem Statistics Log) page
Displays the internal table index.
Minimum measured E /N
b
Average measured E /N
b
Date of the log entry (in YY/MM/DD format).
Time of the log entry (in HH:MM:SS format).
Description
during the configured time interval.
0
during the configured time interval.
0
8–32
