Connector Pinout; 12.3 General Specifications; Table 12-1. Connector Pinout - Comtech EF Data SLM-5650B Installation And Operation Manual

12.2.1

Connector Pinout

The GbE Interface is comprised of one IEEE 802.3ab 1000Base-T copper interface via a single
'RJ-45' type female connector (J1). The LAN interface supports 10/100/1000BASE-T operation.
Pin #
1
2
3
4
5
6
7
8

12.3 General Specifications

Data Framing
Data Framing Format (WAN)
Connector
Electrical Properties
Packet Types
Signal Types
Voltage Level
Packet Latency
Flow Control
Cable Length, Maximum
Hot Pluggable
LEDs
10/100/1000 Base-T (GbE) Interface

Table 12-1. Connector Pinout

Description
BI_DA+
BI_DA-
BI_DB+
BI_DC+
BI_DC-
BI_DB-
BI_DD+
BI_DD-
General Specifications
10/100/1000BASE-T Interface: RFC-894 "Ethernet"
HDLC (Standard Single Channel)
RJ-45 female, 100Ω
Per IEEE 802.3ab
Burst, distributed, or IPV4
Serial data
Per IEEE- 802.3ab
50 ms maximum
None
100 meters CAT 5 cable, patch cords and connecting hardware, per ISO/IEC
11801:1995 and ANSI/EIA/TIA-568-A (1995)
Cable Yes
Link Status, link activity
12–2
SLM-5650B Satellite Modem
Revision 2
Direction
bidirectional
bidirectional
bidirectional
bidirectional
bidirectional
bidirectional
bidirectional
bidirectional
