8.3

Interface Specifications

8.3.1

Physical Description

Dimensions
Connectors
Indicators
8.3.2

General Specifications

Data Framing
Data Framing Format (WAN)
Electrical Properties
Max Ethernet Frame
Packet Types
Signal Types
Voltage Level
Packet Latency
Cable Length, Maximum
Hot Pluggable
Network Processor (NP) Interface
4.5 W x 6.8 D x .85 H inches (11.43 W x 17.27 D x 2.16H cm)
Modem connection: (1) 96-pin DIN receptacle
Console interface for board bring-up and factory use only:
(1) RJ-11 connector
LAN interface: (4) RJ-45 female connectors, 100Ω
Link Status and Activity Light-Emitting Diodes (LEDs)
10/100/1000Base-T Interface: RFC-894 "Ethernet"
CEFD proprietary
Per IEEE 802.3ab
1518 Bytes (all modes)
Burst, distributed, or IPV4
Serial data
Per IEEE- 802.3ab
50 ms maximum
100 meters CAT 5 cable, patch cords and connecting hardware, per
ISO/IEC 11801:1995 and ANSI/EIA/TIA-568-A (1995)
Card – No
Cable – Yes
8–4
SLM-5650B Satellite Modem
Revision 2
MN-SLM-5650B
