Table 3-9. J9 Auxiliary Connector (Hd-15F) Pinout - Comtech EF Data SLM-5650B Installation And Operation Manual

Pin #
1 Demod I Channel
6 Demod Q Channel
11 Reserved for Redundancy Switch
2 Spare
7 AGC Monitor Test Point
12 Reserved for Redundancy Switch
3 Spare
8 Spare
13 Tx TTL Fault
4 Reserved for Redundancy Switch
9 Reserved for Redundancy Switch
14 Rx TTL Fault
5 Chassis Ground
10 Ext Carrier Off
15 Reserved for Redundancy Switch
Rear Panel Connectors and Pinouts

Table 3-9. J9 Auxiliary Connector (HD-15F) Pinout

Signal Function
3–10
SLM-5650B Satellite Modem
Revision 2
Name
I
Q
AGC
TxFLT
RxFLT
GND
EXT
MN-SLM-5650B
