8.2.1

Connector Pinout

The GbE Interface is comprised of one IEEE 802.3ab 1000Base-T copper interface via a single
'RJ-45' type female connector. The LAN interface supports 10/100/1000BASE-T operation.
Pin #
1
2
3
4
5
6
7
8
8.3

General Specifications

Data Framing
Data Framing Format (WAN)
Connector
Electrical Properties
Packet Types
Signal Types
Voltage Level
Packet Latency
Flow Control
Cable Length, Maximum
Hot Pluggable Cable
LEDs
10/100/1000 Base-T (GbE) Interface

Table 8-1. Connector Pinout

Description
BI_DA+
BI_DA-
BI_DB+
BI_DC+
BI_DC-
BI_DB-
BI_DD+
BI_DD-

Table 8-2. GbE Interface General Specifications

General Specifications
10/100/1000BASE-T Interface: RFC-894 "Ethernet"
HDLC (Standard Single Channel)
RJ-45 female, 100Ω
Per IEEE 802.3ab
Burst, distributed, or IPV4
Serial data
Per IEEE- 802.3ab
50 ms maximum
None
100 meters CAT 5 cable, patch cords and connecting hardware, per
ISO/IEC 11801:1995 and ANSI/EIA/TIA-568-A (1995)
Yes
Link Status, link activity
8–2
SLM-5650C / SLM-5650C-ODU Satellite Modem
Direction
bidirectional
bidirectional
bidirectional
bidirectional
bidirectional
bidirectional
bidirectional
bidirectional
