inverters
Goodrive200L
Function
Analog input
Analog output
Digital input
Digital output
Relay output
Encoder interface
Mountable method
Temperature of the
running environment
Ingress protection
Others
Braking unit

3.4 Name plate

Note: This is the example of the name plate for the standard products, and CE\TUV\IP20 will
be marked according to the actual situations.
resolution
1 channel (AI3) -10~10V
2 channels (AO1, AO2) 0~10V /0~20mA
8 channels common input, the Max. frequency:
1kHz, internal impedance: 3.3kΩ;
1 channel high speed input, the Max. frequency:
50kHz
1 channel high speed pulse output, the Max.
frequency: 50kHz;
1 channel Y terminal open collector pole output
2 channels programmable relay output
RO1A NO, RO1B NC, RO1C common terminal
RO2A NO, RO2B NC, RO2C common terminal
Contactor capability: 3A/AC250V,1A/DC30V
Support 24V push-pull output, NPN output interface
Wall, flange and floor mountable
-10~50℃, derate above 40℃
IP20
Cooling Air-cooling
Built-in braking unit for inverters below 30kW
(including 30kW)
External braking unit for others
Built-in C3 filter: meet the degree requirement of
IEC61800-3 C3
EMC filter
External optional filter:meet the degree requirement
of IEC61800-3 C2
L
Fig 3-3 Name plate
Specification
8
Product overview
