7.8 Frequency setting

Goodrive300 series inverters can set the frequency by various means. The given channel can be
divided into main given channel and assistant given channel.
There are two mian given channels: A frequency given channel and B frequency given channel.
These two given channels can carry out mutual simple math calculation between each other. And
the given channels can be shifted dynamically through set multi-funciton terminals.
There are three assistane given channels: keypad UP/DOWN input, terminals UP/DOWN switch
input and digital potentiometer input. The three ways equal to the effect of input UP/DOWN given in
internal assistant given of the inverter. The user can enable the given method and the effect of the
method to the frequency given by setting function codes.
Name
Jogging frequency
Jogging ACC time
Jogging DEC time
ACC time 2
DEC time 2
ACC time 3
DEC time 3
ACC time 4
DEC time 4
Fault reset times
fault reset
Detailed instruction of parameters
21:ACC/DEC time option１
22:ACC/DEC time option２
30:ACC/DEC prohibition
0.00~P00.03(the Max. frequency)
0.0~3600.0s
0.0~3600.0s
0.0~3600.0s
0.0~3600.0s
0.0~3600.0s
0.0~3600.0s
0.0~3600.0s
0.0~3600.0s
0~10
0.1~3600.0s
176
Basic operation instruction
Default
value
5.00Hz
Depend
on model
Depend
on model
Depend
on model
Depend
on model
Depend
on model
Depend
on model
Depend
on model
Depend
on model
1.0s
0
