Repetition Function; Printing Barcode Originals - Riso 9630R User Manual

Chapter 7 Using the Barcode Area Definition Software

Repetition Function

If you use the [Repetition] function when specifying the barcode areas, the areas are specified repeatedly for
subsequent pages based on the value specified for [Cycle] in the [Repetition] dialog box. This eliminates the
need to define the area on each and every page.
• When cycle is 0: The barcode areas are applied only on the pages that are configured in the barcode area
definition file.
• When cycle is 1: The barcode areas configured for the first page in the barcode area definition file are
repeated on each page until the last one.
• When cycle is 2: The barcode areas configured for the first 2 pages in the barcode area definition file are
repeated on every 2 pages until the last one.
• When cycle is 3: The barcode areas configured for the first 3 pages in the barcode area definition file are
repeated on every 3 pages until the last one.
In the example below, barcode areas are defined for 3 pages.
Original data
Barcode area
definition
Cycle: 0
Cycle: 3
• You can specify from 1 to 999 pages for [Cycle].
• The pages after the ones set in the repetition process do not appear in the thumbnails.

Printing Barcode Originals

You can select a registered barcode area definition file from the [Barcode Area Definition] pull-down menu in
the [Image] tab on the printer driver screen.
Select a suitable barcode area definition file when printing a barcode original. (p. 3-26 "Barcode Area
Definition")
7-8
p.1 p.2 p.3 p.4
p.1 p.2 p.3 p.4
The pages that you
configure in a barcode
area definition file
p.1 p.2 p.3 p.4
The pages that you
Repeated pages
configure in a barcode
area definition file
p.5 p.6 p.7 p.8
p.5 p.6 p.7 p.8
Barcode processing is not configured for pages 4 to 13.
p.5 p.6 p.7 p.8
Repeated pages
p.9 p.10 p.11 p.12
p.9 p.10 p.11 p.12
p.9 p.10 p.11 p.12
Repeated pages
ComColor GD Series User's Guide
p.13
p.13
p.13
