Chapter 3 Printing
• When printouts are yellowish, lower the values
of red and green. To adjust other colors, consult
with the administrator for configuration.
Barcode Area Definition
This setting adjusts the print density of the specified
barcode area so that it is suitable for reading.
[Barcode Area Definition]
Select the check box, and select an area definition file to
print from the pull-down menu.
[Details]
Click [Details] to display the [Barcode Area Definition]
dialog box.
[Density Correction]
You can adjust the print density of the specified barcode
area.
[-2] (light), [-1], [Standard]
[Barcode Area Proof]
On printouts with shaded barcode areas, you can check
whether the barcode area definition is out of alignment,
and whether letters or illustrations overlap the 1 mm
(3/64") margin around the barcode.
• When [Barcode Area Definition] is specified,
[Draft] and [CMY Print] in [Image Quality]
cannot be configured. (p. 3-24 "Image Quality")
■ Creating a Barcode Area Definition
File
To use the [Barcode Area Definition] function, use the
Barcode Area Definition Software beforehand to create a
CSV file that specifies the barcode print area for
registering in the printer.
For more information on installing the Barcode Area
Definition Software, specifying the barcode area, and
registereing the definition file in the printer, see "Using
the Barcode Area Definition Software" (p. 7-1).
3-26
■ Checking the Barcode Area
Definition
Select the [Barcode Area Proof] check box and click [OK]
to output a printout for checking. Check whether the
specified area is out of alignment. If the specified area is
not printed in the desired position, use the Barcode Area
Definition Software again to re-configure the barcode
area.
Request for Toner
Collection
RISO KAGAKU CORPORATION
Correct Specification
●Surround the barcode with a margin of 1 mm (3/64") or more.
●The specified area cannot be smaller than the barcode.
●The specified area must be aligned with the barcode.
●Do not include another object with the barcode.
Any non-black image inside the specified area is printed out white
(disappears).
ComColor GD Series User's Guide
Specified
barcode
area
(shaded
part)
OK
Wrong
Wrong
Wrong
